Page 4665 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Power-Out 1. Move switch to the power-out position. 2. Check for continuity between pins (1) and (4). 3. Check for continuity between pins (2) and (5). Power-In 1. Move switch to the power-in position

Page 4666 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Low Voltage Interrupt (LVI) Test If the LVI is suspected to be failing check the following: 1. Check to make sure the battery has 10.5 to 12 volts. 2. If low, charge battery. 3. Wait for 30 seconds or

Page 4667 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Measurement between pinsResistance Voltage Results Correction (V) “4” to “5” 2 - Yes Relay pack OK. No 1. Check for any faulty relay or motor electrical connections and repair if necessary. 2.

Page 4668 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2. Remove the winch support bolts (1). 3. Remove the lower frame bracket (2) bolts (6) and loosen the upper bolts (1). 4. Support the winch using a jack or other suitable lift device. 5. Lift the winc

Page 4669 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8. Remove the nut and disconnect the ground cable (1) from the motor (2). 9. Disconnect the three cables connected to the motor on the studs marked F1 (2) , F2 (1) and A (3). 10. Disconnect the therma

Page 4670 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 12. Remove the four winch mounting and roller bracket bolts (3). 13. Separate the mounting bracket assembly (1) from the winch assembly. INSTALLATION 1. Position the winch (2) onto the support bracket

Page 4671 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Position the relay pack onto the motor and tighten thebandclamps(2). 4. Connect the thermal switch electrical connector.

Page 4672 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Connect the three cables connected to the motor on the studs marked F1 (2) , F2 (1) and A (3). 6. Tighten the nuts to 7 Nꞏm (60 in. lbs.). 7. Install the ground cable and install the bolt (1). 8.
