Page 4681 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Install the support bracket (1) and install the bolts (3). 6. Tighten the bolts to 108 Nꞏm (80 ft. lbs.). 7. Position the wire rope through the roller opening and install the roller (4), shaft (3

Page 4682 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual MOTOR-TIE RODS REMOVAL 1. Remove the winch assembly. (Refer to 23 - BODY/WINCH - REMOVAL) 2. Remove the bolts and remove the damaged tie rod(s). INSTALLATION 1. Install the tie rod(s) and install the

Page 4683 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual RELAY REMOVAL 1. Remove the relay pack (1). (Refer to 23 - BODY/ WINCH/RELAY PACK - REMOVAL) 2. Remove the nuts (2 & 3), disconnect the cables and remove the bus straps (4).

Page 4684 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual NOTE: Relay #4 shown, all others similar. 3. Remove the nuts (1) and disconnect the control wires (2). 4. Slide the relay (1) out of the retaining tab (2) and remove.

Page 4685 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION NOTE: Relay #4 shown, all others similar. 1. Slide the relay (1) into the retaining tab (2). 2. Install the control wires (2) and install the nuts (1). 3. Tighten the nuts to 3 Nꞏm (25

Page 4686 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Install the bus straps (4) and connect the cables. 5. Install the nuts (2 & 3) and tighten to 9.5 Nꞏm (85 in. lbs.). 6. Install the relay pack (1). (Refer to 23 - BODY/ WINCH/RELAY PACK - INSTALL

Page 4687 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual RELAY PACK DESCRIPTION Electrical operation of the control assembly consists of four heavy duty relays, a thermal-switch located on the motor armature brush holder and a Low Voltage Interrupt (LVI) lo

Page 4688 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual In power-in mode, relay number 1 and 4 are energized. Current again flows from the battery positive cable, but this time current flows through solenoid number 1 then through field winding number 1. Cu
