Page 4209 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Installer, Seal - 8841

Page 4210 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SEAL-EXTENSION HOUSING REMOVAL 1. Raise and support vehicle. 2. Remove rear propeller shaft. (Referto 3 - DIFFERENTIAL & DRIVELINE/PROPELLER SHAFT/PROPELLER SHAFT - REMOVAL) 3. Using a suitable pry to

Page 4211 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual FLUID STANDARD PROCEDURE - FLUID DRAIN AND REFILL The fill (2) and drain (3) plugs are both in the rear case. 1. Raise vehicle. 2. Position drain pan under transfer case. NOTE: It may be necessary to

Page 4212 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SEAL-FRONT OUTPUT SHAFT REMOVAL 1. Remove the front propeller shaft (Refer to 3 - DIF- FERENTIAL & DRIVELINE/PROPELLER SHAFT/ PROPELLER SHAFT - REMOVAL). 2. Remove the front propeller shaft seal boot

Page 4213 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Using a suitable pry tool (2), remove the slinger (1) from the output shaft using care not to damage the shaft. 6. Using a screw and a slide hammer, remove the front output shaft seal. INSTALLATION

Page 4214 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SENSOR-MODE DESCRIPTION The transfer case mode sensor (1) is an electronic device whose output can be interpreted to indicate the shift motor shaft’s rotary position. The sensor consists of a magnet

Page 4215 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Transfer Case Angle (degrees)Sensor Channel A Sensor Channel B Sensor Channel C Sensor Channel D 0 (2WD/AWD) H L H L Between Gears H L H H Between Gears L L H H -20 (4HI) L L H L Between Gears L L H H

Page 4216 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SWITCH-SELECTOR DESCRIPTION The selector switch assembly is mounted in the left side of the vehicle’s Instrument Panel (IP) and con- sists of a rotary knob connected to a resistive network for the m
