14. Insert magnet (1) in front case pocket (2).
OIL PUMP AND REAR CASE
Lubricate the oil pump components with transmission
fluid before installation. Prime the oil pickup tube by
pouring a little oil into the tube before installation.
CAUTION: Do not remove the bolts holding the oil
pump cover to the rear case half. The oil pump
cover is aligned to the rear output shaft inner
bearing race and will become mis-aligned if the
bolts are loosened. If the transfer case failure has
generated any debris which may have become
trapped in the oil pump. the rear case and oil
pump assembly MUST be replaced.
1. Install new o-ring in pickup tube inlet of oil pump, if
necessary.
2. Insert oil pickup tube into the oil pump.
3. Apply bead of Mopar
Gasket Maker, or equivalent,
to mating surface of front case. Keep sealer bead width to maximum of 3/16 inch. Do not use excessive amount
of sealer as excess will be displaced into case interior.
4. Align oil pump with mainshaft and align shift rail with bore in rear case.Then install rear case and oil pump
assembly (1).
5. Install rear output bearing snap-ring (3) to output
shaft (1).
Page 4250 of 5267
6. Install 4-5 rear case-to front case bolts (3) to hold
rear case (1) in position. Tighten bolts snug but not
to specified torque at this time.
CAUTION: Verify that shift rail, and case alignment
dowels are seated before installing any bolts.
Case could be cracked if shaft rail or dowels are
misaligned.
7. Apply Mopar
Lock ’n Seal Adhesive to remainder
of rear case-to-front case bolt threads and install
bolts. Tighten bolts to 25-28 Nꞏm (18-21 ft. lbs.),
SEAL BOOT AND SHIFT MOTOR ASSEMBLY
1. Install a new seal boot clamp onto the seal boot.
2. Install the seal boot (2) and clamp onto the slinger
(2) hub and tighten the clamp with Crimp Tool
C-4975-A.
3. Position the shift motor and mode sensor assembly
onto the transfer case.
4. Install the bolts (3) to hold the shift motor and
mode sensor assembly (2) to the transfer case (1).
Tighten the bolts to 16-25 Nꞏm (12-18 ft. lbs.).
Page 4251 of 5267

REAR EXTENSION
1. Install new seal in rear extension housing seal with
Seal Installer D-163 and Universal Handle C-4171.
Verify that the weep hole in the rubber is oriented
downward.
2. Apply bead of Mopar
Gasket Maker, or equivalent,
to mating surface of rear extension housing. Keep
sealer bead width to maximum of 3/16 inch. Do not
use excessive amount of sealer as excess could
be displaced into output bearing.
3. Align and install rear extension (1) on the transfer
case (2).
4. Apply Mopar
Silicone Sealer to threads of rear
extension housing bolts. Then install and tighten
bolts to 16-24 Nꞏm (12-18 ft. lbs.) torque.
INSTALLATION
1. Mount transfer case on a transmission jack.
2. Secure transfer case to jack with chains.
3. Position transfer case under vehicle.
4. Align transfer case and transmission shafts and install transfer case onto the transmission.
5. Install and tighten transfer case attaching nuts to 27-34 Nꞏm (20-25 ft.lbs.) torque.
6. Connect the vent hose.
7. Connect the shift motor and mode sensor wiring connectors. Secure wire harness to clips on transfer case.
8. Align and connect the propeller shafts. (Refer to 3 - DIFFERENTIAL & DRIVELINE/PROPELLER SHAFT/FRONT
PROPELLER SHAFT - INSTALLATION) (Refer to 3 - DIFFERENTIAL & DRIVELINE/PROPELLER SHAFT/REAR
PROPELLER SHAFT - INSTALLATION)
9. Fill transfer case with correct fluid. (Refer to 21 - TRANSMISSION/TRANSFER CASE/FLUID - STANDARD PRO-
CEDURE)
10. Install skid plate, if equipped.
11. Remove transmission jack and support stand.
12. Lower vehicle and verify transfer case shift operation.
SPECIFICATIONS
TRANSFER CASE - NV244 GENII
TORQUE SPECIFICATIONS
DESCRIPTION N-m Ft. Lbs. In. Lbs.
Plug, Detent 16-24 12-18 -
Plug, Drain/Fill 20-34 15-25 -
Bolt, Extension Housing 16-24 12-18 -
Bolt, Case Half 25-28 18-21 -
Screw, Oil Pump 14-19 10-14 -
Nuts, Mounting 30-41 20-30 -
Bolts, Shift Motor and
Mode Sensor Assembly16-24 12-18 -
Page 4252 of 5267
SPECIAL TOOLS
TRANSFER CASE - NV244 GENII
Handle, Universal - C-4171
Installer, Seal - D-163
Remover - L-4454
Installer, Seal - MB991168A
Installer, Bushing - 5065
Installer, Bushing - 5066
Installer, Bearing - 6953
Cup - 8148
Installer - 8840
Page 4253 of 5267
Page 4254 of 5267
SEAL-EXTENSION HOUSING
REMOVAL
1. Raise and support vehicle.
2. Remove rear propeller shaft. (Referto 3 - DIFFERENTIAL & DRIVELINE/PROPELLER SHAFT/PROPELLER
SHAFT - REMOVAL)
3. Using a suitable pry tool or slide-hammer mounted screw, remove the extension housing seal.
INSTALLATION
1. Clean fluid residue from sealing surface and
inspect for defects.
2. Using Seal Installer D-163 (2) and Universal Han-
dle C-4171 (1), install seal in extension housing.
3. Install propeller shaft. (Refer to 3 - DIFFERENTIAL
& DRIVELINE/PROPELLER SHAFT/PROPELLER
SHAFT - INSTALLATION)
4. Verify proper transfer case fluid level.
5. Lower vehicle.
Page 4255 of 5267

FLUID
STANDARD PROCEDURE - FLUID DRAIN AND REFILL
NOTE: The fill (2) and drain (3) plugs are both in
the rear case.
1. Raise vehicle.
2. Position drain pan under transfer case.
NOTE: It may be necessary to remove the exhaust
y-pipe at the exhaust manifold to properly access
the fill and drain plugs. Lowering the exhaust will
allow the plugs to be accessed for torquing during
installation. (Refer to 11 - EXHAUST SYSTEM/EX-
HAUST PIPE - REMOVAL)
3. Remove drain (3) and fill (2) plugs and drain lubri-
cant completely.
4. Install drain plug (3). Tighten plug to 20-34 Nꞏm
(15-25 ft. lbs.).
5. Remove drain pan.
6. Fill transfer case to bottom edge of fill plug opening with Mopar
ATF +4, Automatic Transmission fluid.
7. Install and tighten fill plug (2) to 20-34 Nꞏm (15-25 ft. lbs.).
8. Install the exhaust y-pipe to the exhaust manifold, if removed. (Refer to 11 - EXHAUST SYSTEM/EXHAUST
PIPE - INSTALLATION)
9. Wipe any excess fluid that mayhave spilled onto the exhaust.
10. Lower vehicle.
Page 4256 of 5267
SEAL-FRONT OUTPUT SHAFT
REMOVAL
1. Remove the front propeller shaft (Refer to 3 - DIF-
FERENTIAL & DRIVELINE/PROPELLER SHAFT/
PROPELLER SHAFT - REMOVAL).
2. Remove the front propeller shaft seal boot retaining
clamp (2).
3. Remove the front propeller shaft seal boot (1) from
the front output shaft seal slinger (2).
4. Remove the front output shaft seal slinger (1) by
bending the slinger away (2) from the transfer
case.
5. Using a suitable pry tool, remove the slinger from
the output shaft using care not to damage the
shaft.
6. Using a screw and a slide hammer, remove the
front output shaft seal.
