Page 2641 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Install second gear bearing (1) on mainshaft (2). 7. Install second gear (1) on mainshaft (2). 8. Install second gear inner friction ring (1) on second gear (2).

Page 2642 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 9. Install second gear outer friction ring (1) on second gear (2). 10. Install second gear blocker ring (1) on second gear (2).

Page 2643 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 11. Align 1-2 synchronizer hub (1) with blocker ring on mainshaft and install hub with Installer D-389 (2). NOTE: If 1-2 synchronizer hub is installed incor- rectly the snap ring groove will not be vi

Page 2644 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 13. Install 1-2 synchronizer hub (1) detents (2). 14. Install 1-2 synchronizer sleeve (2) on 1-2 hub (1). NOTE: Align grooves in the sleeve with detents in hub. 15. Install first gear blocker ring (1)

Page 2645 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 16. Install first gear outer friction ring (1) on 1-2 hub (2). 17. Install first gear inner friction ring (1) on 1-2 hub (2). 18. Install first gear bearing (1) on mainshaft (2).

Page 2646 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 19. Install first gear (1) on mainshaft (2). WARNING: Use welding gloves or tongs when handling heated components. Failure to follow these instructions will result in personal injury. CAUTION: A beari

Page 2647 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 22. Install reverse gear bearing (1) on bearing race (2). 23. Install reverse gear (1) on mainshaft (2). 24. Install reverse gear friction/blocker ring (1) on reverse gear (2).

Page 2648 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 25. Install reverse synchronizer detents (1) in reverse hub (2). 26. Install reverse synchronizer sleeve (1) on reverse hub (2). NOTE: Align grooves in the sleeve with detents in hub. 27. Install reve
