Page 2697 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Press third gear (1) and 3-4 synchronizer hub (2) onto the mainshaft with Splitter 9375. 4. Install 3-4 synchronizer sleeve. 5. Install 3-4 synchronizer (1)originalornewsnap ring (2). 6. Press seco

Page 2698 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Install 1-2 thrust washer and blocker ring (1) assembly onto 1-2 synchronizer (2). 8. Installoriginalornew1-2 synchronizer (1) snap ring (2) on mainshaft. 9. Install first gear (1) and bearing (2)

Page 2699 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 10. Install rear mainshaft tapered bearing (1) on top of first gear (2). TRANSMISSION HOUSING NOTE: During assembly refer to Adjustments for Main shaft and Countershaft End Play 1. Install input shaft

Page 2700 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Install countershaft (1) assembly into adapter. 4. Tilt countershaft (4) sideways then install mainshaft (1) and shift rail (2) assemblies into adapter (3).

Page 2701 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Install reverse rail assembly (2) into adapter (3) and on mainshaft (1). 6. Install guide plate and tighten torx bolts to 22 Nꞏm (16 ft. lbs.). 7. Apply Mopar Gasket Maker to adapter sealing surf

Page 2702 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 9. Install front adapter (2) bolts (3) and tighten to 34 Nꞏm (25 ft. lbs.). 10. Install two torx screws (2) on top of transmission case (1). 11. Drive roll pin down into offset lever (3) with ham- m

Page 2703 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 12. Apply Loctite242 to shift detente (1) threads. Install shift detente assembly withnewO-ring and tighten to 34 Nꞏm (25 ft. lbs.). 13. Install reverse lock-out solenoid. 14. Apply Mopar Gasket Mak

Page 2704 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 18. Install 5-6 synchronizer (1) on countershaft (2). 19. Install 5-6 synchronizer snap ring. 20. Install 5-6 shift fork (1) and synchronizer sleeve (2). 21. Installnew5-6gearshiftfork(1)snapring(2).
