DODGE RAM SRT-10 2006 Service Repair Manual FRONT TOW HOOK ASSEMBLY REMOVAL 1. Remove front bumper (Refer to 13 - FRAME & BUMPERS/BUMPERS/FRONT BUMPER - REMOVAL). 2. Remove the bolts (2) and remove the tow hook assembly (3). 3. If the vehicle i

Page 2226 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Install the tow hook assembly (3) and bolts (2) hand tight. 2. If vehicle is aHeavy Duty, install the tow hook (2) and bolts (1) hand tight. 3. Install the front bumper (Refer to 13 -

Page 2227 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual TRANSMISSION CROSSMEMBER REMOVAL 1. Raise and support the vehicle (Refer to LUBRICA- TION & MAINTENANCE/HOISTING - STANDARD PROCEDURE). 2. Remove the transfer case skid plate (3 - if equipped) (Refer

Page 2228 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Support the transmission (1) with a transmission jack (2) or suitable lifting device. 4.2WD Vehicles- Remove the transmission mount nuts (3). 5. Remove the bolts and remove the crossmember (2). 6.4

Page 2229 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. OnLight Duty Vehicles, install the crossmember (2) and the bolts (4). Tighten the bolts to 102 Nꞏm (75 ft. lbs.). 2. Install the transmission mount nuts and tighten to 54 Nꞏm (40 f

Page 2230 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Install the transfer case skid plate (3 - if equipped) (Refer to 13 - FRAME & BUMPERS/FRAME/ TRANSFER CASE SKID PLATE - INSTALLATION).

Page 2231 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual TRAILER HITCH REMOVAL 1. Remove the rear bumper (Refer to 13 -FRAME & BUMPERS/BUMPERS/REAR BUMPER-REMOVAL). 2. OnLight Duty Vehicles, remove the hitch bolts (7)

Page 2232 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. OnHeavy Duty Vehicles, remove the hitch bolts (8) 4. Disconnect all wire harness support push pins. 5. Remove the rear two cargo box bolts (3) and loosen the remaining bolts (Refer to 23 - BODY/ EX
