2006 DODGE RAM SRT-10 Service Repair Manual

Page 4617 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual CHANNEL-DRAIN
REMOVAL
1. Remove glass panel. (Refer to 23 - BODY/SUN-
ROOF/GLASS PANEL - REMOVAL)
2. Separate the drain channel arms (2) from the guide
mechanisms (1) one at a time.
CAUTION: Do not pr

Page 4618 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual INSTALLATION
1. Carefully position the drain channel (1) into the
notches (2) in the frame and slide rearward.
2. Install the drain channel arms (2) into the mecha-
nism (1) holes one at a time with t

Page 4619 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual COVER-GUIDE MECHANISM
REMOVAL
1. Move the glass panel to the full closed position.
2. Slide sunshade rearward to the open position.
3. Separate the mechanism covers (2) from the tabs
(1) on the glass

Page 4620 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual INSTALLATION
1. With the sunroof in the open position, snap the mechanism cover (2) into the lower guide channel.
2. Hold down each cover and close the sunroof.
3. Snap the upper portion of the cover

Page 4621 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual DEFLECTOR-WIND
REMOVAL
1. Open the sunroof fully.
2. Remove the strap screws (2) from the beam area
release the strap (3).
3. Rotate the deflector up and remove springs (2)
from the holes in the frame

Page 4622 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual INSTALLATION
1. Position the deflector spring arms (2) into the holes
of the frame (1).
2. Rotate the deflector down, attach the straps (3)
and install the strap screws (2) into the front beam.
3. Ver

Page 4623 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual GLASS
REMOVAL
1. Move the glass panel to the full closed position.
2. Slide sunshade rearward to the open position.
3. Separate the mechanism covers (2) from the tabs
(1) on the glass panel.
4. Remove

Page 4624 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual INSTALLATION
1. Position glass panel on to mechanism lift arms.
CAUTION: Verify that the retaining tabs are located on the INSIDE of the guide mechanism arms.
2. Start the attaching screws (3).
3. Con
