DODGE RAM SRT-10 2006 Service Repair Manual FRONT BUMPER REMOVAL 1. Using a grease pencil or equivalent, mark the posi- tion of the bumper support bracket (5) on the frame rail tip (7) to aid installation. 2. Disconnect the fog lamp electrical

Page 2178 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual FRONT FASCIA REMOVAL ST/SLT/SLT+ 1. Remove the two screws (4) at each trailing edge of the fascia. 2. Remove the four push pin fasteners (5) from the upper edge of the close out panel. 3. Using a trim

Page 2179 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2. Remove the three screws (3) at each trailing edge of the fascia. 3. Remove the five lower screws (8). 4. Remove and discard the four upper push pins (7). 5. Using a trim stick (special tool #C-4755

Page 2180 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual REAR BUMPER REMOVAL 1. Raise and support the vehicle (Refer to LUBRICA- TION & MAINTENANCE/HOISTING - STANDARD PROCEDURE). 2. Remove the license plate. 3. Remove the bolts behind the plate. 4. Disconn

Page 2181 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Align the holes in the bumpers to the trailer hitch pins and install the bumper. 2. Loosely install the hitch bolts (2) in the support bracket (4). 3. Install the front upper edge to t

Page 2182 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual FASCIA-FRONT SRT-10 REMOVAL 1. Remove the belly pan screws (1). 2. Remove the screws (1 & 2) from the wheel well.

Page 2183 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Remove the push pin fasteners attaching the upper fascia to the fascia retainer. 4. Lift the fascia off of the support brackets (1 & 2) and remove the fascia.

Page 2184 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Position the fascia onto the vehicle. 2. Position the fascia (2) over the side support bracket (1) on one side then around and over the other side support bracket (1).
