DODGE RAM SRT-10 2006 Service Repair Manual 25. Remove thrust plate (1) from intermediate shaft
hub (2).
26. Remove intermediate shaft-planetary geartrain
assembly (1).
27. Loosen rear band locknut and loosen adjusting
screw 3-4 turns.
28. Remo

Page 3826 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 29. Slide low-reverse drum (1) and thrust washer (3)
off piston retainer hub and out of rear band.
30. Note that overrunning clutch race (1) will remain
on splines of low-reverse drum after removal.Th

Page 3827 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 32. Remove rear band adjusting lever and reaction
pin.
33. Remove rear band.
34. Compress front servo rod guide (2) with large
C-clamp (1) and Tool C-4470 (4), or Compressor
Tool C-3422-B. Compress gu

32. Remove rear band adjusting lever and reaction
pin.
33. Remove rear band.
34. Compress front servo rod guide (2) with large
C-clamp (1) and Tool C-4470 (4), or Compressor
Tool C-3422-B. Compress guide only enough to
permit snap-ring removal (about 1/8 in.).
35. Remove servo piston snap-ring (4). Unseat one
end of ring. Then carefully work removal tool
around back of ring until free of ring groove.Exer-
cise caution when removing snap-ring. Servo
bore can be scratched or nicked if care is not
exercised.
36. Remove tools and remove rear servo retainer (3),
spring and piston assembly.
CLEANING
Clean the case in a solvent tank. Flush the case bores and fluid passages thoroughly with solvent. Dry the case and
all fluid passages with compressed air. Be sure all solvent is removed fromthe case and that all fluid passages are
clear.
NOTE: Do not use shop towels or rags to dry the case (or any other transmission component) unless they
aremadefromlint-freematerials.Lintwillsticktocasesurfacesandtransmission components and circu-
late throughout the transmission after assembly. A sufficient quantity of lint can block fluid passages and
interfere with valve body operation.
Lubricate transmission parts with Mopar
ATF +4, Automatic Transmission fluid, during overhaul and assembly. Use
petroleum jelly to prelubricate seals, O-rings, and thrust washers. Petroleumjellycanalsobeusedtoholdpartsin
place during reassembly.
INSPECTION
Inspect the case for cracks, porous spots, worn bores, or damaged threads.Damaged threads can be repaired with
Helicoil thread inserts. However, the case will have to be replaced if it exhibits any type of damage or wear.
Lubricate the front band adjusting screw threads with petroleum jelly andthread the screw part-way into the case.
Be sure the screw turns freely.
Inspect the transmission bushings during overhaul. Bushing condition isimportant as worn, scored bushings con-
tribute to low pressures, clutch slipand accelerated wear of other components. However, do not replace bushings
as a matter of course. Replace bushings only when they are actually worn, orscored.

Page 3828 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual The use of crocus cloth is permissible where necessary, providing it is usedcarefully.Whenusedonshafts,or
valves, use extreme care to avoid rounding off sharp edges. Sharp edges arevital as they preve

The use of crocus cloth is permissible where necessary, providing it is usedcarefully.Whenusedonshafts,or
valves, use extreme care to avoid rounding off sharp edges. Sharp edges arevital as they prevent foreign matter
from getting between the valve and valve bore.
Do not reuse oil seals, gaskets, seal rings, or O-rings during overhaul. Replace these parts as a matter of course.
Also do not reuse snap rings or E-clips that are bent or distorted. Replace these parts as well.
ASSEMBLY
Do not allow dirt, grease, or foreign material to enter the case or transmission components during assembly. Keep
the transmission case and components clean. Also make sure the tools and workbench area used for reassembly
operations are equally clean.
Shop towels used for wiping off tools and your hands must be made fromlint freematerials. Lint will stick to trans-
mission parts and could interfere with valve operation or even restrict fluid passages.
Lubricate transmission clutch and gear components with Mopar
ATF +4 during reassembly. Soak clutch discs in
transmission fluid before installation.
Use petroleum jelly on piston seals and o-rings to ease installation. Petroleumjellycanalsobeusedtolubricate
and hold thrust washers and plates in position during assembly.
Do not use chassis grease, bearing grease, white grease, or similar lubricants on any part.These types of
lubricants can eventually block or restrict fluid passages and valve operation. Use petroleum jelly only.
Do not force parts into place. The transmission components and sub-assemblies are easily installed by hand when
properly aligned. If a part seems difficult to install, it is either misaligned or incorrectly assembled. Verify that thrust
washers, thrust plates and seal rings are correctly positioned.
The planetary geartrain, front/rear clutch assemblies and oil pump are all much easier to install when the transmis-
sion case is upright. Either tilt the case upward with wood blocks, or cut a hole in the bench large enough for the
intermediate shaft and rear support. Then lower the shaft and support intothe hole and support the rear of the case
directly on the bench.
FRONT/REAR SERVO
1. Lubricate rear servo piston seal with ATF +4. Lubri-
cateservoboreincasewithATF+4.
2. Install rear servo piston (1) in case. Position piston
at slight angle to bore and insert piston with twist-
ing motion.

Page 3829 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Install rear servo spring (1) and retainer (3) in case
bore. Be sure spring (1) is seated on piston (2).
4.CompressrearservopistonwithC-clamp(2)or
Valve Spring Compressor C-3422-B and install
servo

Page 3830 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Bottom front servo piston in bore and install servo
spring.
8. Install front servo piston rod (2) guide as follows:
a. Place Tool SP-5560 (or similar size tool) (5) on
guide and position C-clamp on

Page 3831 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Lubricate intermediate shaft thrust plate (1) with
petroleum jelly and install plate on shaft pilot hub
(2).
4. Check input shaft front seal rings (1), fiber thrust
washer (4), and rear seal ring (

Page 3832 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Assemble front (1) and rear (2) clutches. Align lugs
on front clutch discs. Mount front clutch on rear
clutch. Turn front clutch retainer back and forth until
front clutch discs are fully seated on
