DODGE RAM SRT-10 2006 Service Repair Manual EXHAUST SYSTEM DESCRIPTION GAS ENGINES CAUTION: Avoid application of rust prevention compounds or undercoatingmaterials to exhaust system floor pan exhaust heat shields. Light overspray near the edges

Page 2138 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual The exhaust system must be properly aligned to prevent stress, leakage andbody contact. Minimum clearance between any exhaust component and the body or frame is 25.4 mm (1.0 in.). If the system contac

Page 2139 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DIAGNOSIS AND TESTING GAS ENGINE EXHAUST SYSTEM DIAGNOSIS CHART CONDITION POSSIBLE CAUSE CORRECTION EXCESSIVE EXHAUST NOISE OR LEAKING EXHAUST GASES1. Leaks at pipe joints. 1. Tighten clamps/bolts at

Page 2140 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DIESEL ENGINE EXHAUST SYSTEM DIAGNOSIS CHART CONDITION POSSIBLE CAUSE CORRECTION EXCESSIVE EXHAUST NOISE OR LEAKING EXHAUST GASES1. Leaks at pipe joints. 1. Tighten clamps/bolts at leaking joints. 2.

Page 2141 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DESCRIPTION Nꞏm Ft. Lbs. In. Lbs. Bolts-Turbocharger Oil Drain Tube-(Diesel) 24 18 - Fitting-Turbocharger Oil Supply Line-(Diesel) 36 27 - Nut-Turbocharger V-Band Clamp Cast Elbow to Turbocharger- (

Page 2142 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SPECIAL TOOLS TURBOCHARGER TESTER 9022

Page 2143 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CONVERTER-CATALYTIC DESCRIPTION WARNING: THE NORMAL OPERATING TEMPERATURE OF THE EXHAUST SYSTEM IS VERY HIGH. THERE- FORE, NEVER WORK AROUND OR ATTEMPT TO SERVICE ANY PART OF THE EXHAUST SYSTEMUNTIL I

Page 2144 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5.7L ENGINE 1. Raise and support vehicle. 2. Saturate the bolts and nuts with heat valve lubri- cant. Allow 5 minutes for penetration. 3. Disconnect oxygen sensor electrical connectors. 4. Remove clam
