DODGE RAM SRT-10 2006 Service Repair Manual 3. Install sixth gear (1) on mainshaft (2). 4. Install sixth gear clutch body (1) on sixth gear (2). 5. Install sixth gear friction ring (1) on clutch body (2).

Page 2626 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Install 5-6 synchronizer hub (1) on mainshaft with Installer W-262 (2). 7. Install 5-6 synchronizer hub (1) snap ring (2).

Page 2627 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8. Install 5-6 synchronizer detents (1) in hub (2). 9. Install 5-6 synchronizer sleeve (1) on hub (2). NOTE: Align grooves in the sleeve with detents in hub. 10. Install fifth gear synchronizer fricti

Page 2628 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 11. Install fifth gear synchronizer clutch body (1) on 5-6 synchronizer hub (2). COUNTERSHAFT 1. Install countershaft center support bearing (1) on countershaft (2).

Page 2629 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CENTER SUPPORT 1. Install center support (1) countershaft roller bearing race with Installer/Remover 9617 (2) and Handle C-4171. 2. Install center support (1) mainshaft roller bearing race with Instal

Page 2630 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Install center support (1) race retainer screw (2) andtightento22Nꞏm(16ft.lbs.). REAR HOUSING 1. Install mainshaft bearing (1) in rear housing with hammer and driver. 2. Install mainshaft bearing

Page 2631 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Install shift rail roller bearing (1) with Installer 8475 (2). 4. Install countershaft bearing with Installer 9624 (1) and Handle C-4171 (2). 5. Install idler gear (1) in rear housing (2).

Page 2632 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Install idler gear bearing (1) in idler gear (2). 7. Install idler gear (1) shaft support (2). 8. Install idler gear (2) shaft (1).
