Page 4401 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Carefully lower the door glass into the door through the window opening. 2. Rotate the door glass into position and engage it to the window regulator. 3. Position the front glass run c

Page 4402 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual EXTERIOR HANDLE REMOVAL 1. Remove the front glass run channel (Refer to 23 - BODY/DOORS - REAR/GLASS RUN CHANNEL - REMOVAL). 2. Disconnect the actuator rod (1) from the exterior door handle (2). 3. Re

Page 4403 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual GLASS RUN CHANNEL REMOVAL FRONT 1. Raise the window glass to the full up position and remove the window regulator (Refer to 23 - BODY/ DOORS - REAR/WINDOW REGULATOR - REMOVAL). 2. Remove the two bolts

Page 4404 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual REAR 1. Raise the window glass to the full up position and remove the window regulator (Refer to 23 - BODY/ DOORS - REAR/WINDOW REGULATOR - REMOVAL). 2. Remove the two bolts (2) that secure the rear g

Page 4405 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Mega Cab Models 1. If removed, install the weatherstrip onto the front glass run channel (2). 2. Position the front glass run channel into the door through the door panel opening. 3. Install the two b

Page 4406 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual HINGE REMOVAL NOTE:Itisnotnecessarytoremovethedoortoreplacethehingesiftheyarereplaced one at a time. NOTE: The epoxy coated washers should not be removed from the hinge. If the washers are removed the

Page 4407 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual LOWER HINGE 1. Using a grease pencil or equivalent, mark the posi- tion of the hinge on the door and b-pillar. 2. Remove the lower b-pillar trim. (Refer to 23 - BODY/INTERIOR/B-PILLAR LOWER TRIM - REM

Page 4408 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION UPPER HINGE 1. Install the hinge to door washers, if there were removed previously, nut (1) and bolt (9) and tighten to 28 Nꞏm (21 ft. lbs.). 2. Tighten the upper hinge bolt (2) to 28 N
