Page 4369 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Tighten the upper hinge bolt (1) to hinge pillar to 28 Nꞏm (21 ft. lbs.). 8. Tighten the lower hinge bolt (2) to hinge pillar to 28 Nꞏm (21 ft. lbs.). 9. Tighten the remaining hinge to hinge pi

Page 4370 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual IN/OUT NOTE: In/out door adjustment is done by loosen- ing the hinge to door fasteners one hinge at a time and moving the door to the correct position. NOTE: When adjustment of the door requires the l

Page 4371 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DOOR GLASS REMOVAL 1. Remove the inner belt molding (Refer to 23 - BODY/WEATHERSTRIP/SEALS/FRONT DOOR INNER BELT WEATHERSTRIP - REMOVAL). 2. Remove the waterdam (Refer to 23 - BODY/DOOR - FRONT/WATERD

Page 4372 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Carefully lower the door glass into the door (5) through the window opening. 2. Rotate the door glass into position and engage it to the window regulator. 3. Position the front glass r

Page 4373 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual EXTERIOR HANDLE REMOVAL 1. Disconnect and isolate the negative battery cable. 2. Remove the door glass (Refer to 23 - BODY/ DOOR - FRONT/DOOR GLASS - REMOVAL). 3. If equipped, disconnect the exterior

Page 4374 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual GLASS RUN CHANNEL REMOVAL FRONT-ALL MODELS 1. Raise the window glass to the full up position and remove the window regulator (Refer to 23 - BODY/ DOOR - FRONT/WINDOW REGULATOR - REMOVAL). 2. Loosen th

Page 4375 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual REAR-STANDARD CAB 1. Raise the window glass to the full up position and remove the window regulator (Refer to 23 - BODY/ DOOR - FRONT/WINDOW REGULATOR - REMOVAL). 2. Remove the two bolts (1) that secu

Page 4376 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual REAR-QUAD CAB 1. If removed, install the weatherstrip onto the rear glass run channel (3). 2. Position the rear glass run channel into the door through the door panel opening (2). 3. Engage the upper
