DODGE RAM SRT-10 2006 Service Repair Manual 4. Remove the differential snap-ring (1). 5. Remove the differential assembly (1) from the mainshaft (2). 6. Remove the mode hub (2) and mode hub retainer from the differential assembly (1).

Page 4234 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Remove the mode hub retainer (1) from the mode hub (2). INPUT AND PLANETARY GEAR 1. Remove input gear seal with suitable screw and slide hammer. 2. Remove input gear retaining ring (2) with heavy d

Page 4235 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INPUT AND PLANETARY GEAR 1. Remove snap-ring (1) that retains input gear in low range gear. 2. Remove retainer (3). 3. Remove front tabbed thrust washer (1).

Page 4236 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Remove input gear (1). 5. Remove rear tabbed thrust washer (2) from low range gear (1). CLEANING Clean the transfer case parts with a standard parts cleaning solvent. Remove all traces of sealer fr

Page 4237 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INPUT GEAR AND PLANETARY CARRIER Check the teeth on the gear. Minor nicks can be dressed off with an oilstone but replace the gear if any teeth are broken, cracked, or chipped. The bearing surface on

Page 4238 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual REAR EXTENSION HOUSING Inspect the extension housing seal and bushing. Replace both components if either show any sign of wear or dam- age. FRONT OUTPUT SHAFT AND DRIVE CHAIN Inspect the shaft splines

Page 4239 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual ASSEMBLY BEARINGS AND SEALS 1. Remove the input shaft bearing (1) from the front case (2) with suitable snap-ring pliers. 2. Transfer the retaining ring to the new bearing if necessary and install the

Page 4240 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8. Install new bearing with Universal Handle C-4171 (1) and Bushing Installer 5066 (3). 9. Remove the rear output shaft bearing from the rear case using Bushing Installer 5065 (2) and Univer- sal Hand
