Page 4697 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Install the roller bushings (1) onto the rollers (2). 5. Install the roller axle rods (3) and install the rollers (4) onto the support bracket (2). 6. Install the clips (1). 7. Store the winch hook

Page 4698 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual page page GAP AND FLUSH SPECIFICATIONS ............................ 362 OPENING DIMENSIONS SPECIFICATIONS ............................ 367 SEALER LOCATIONS SPECIFICATIONS ............................

Page 4699 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual GAP AND FLUSH SPECIFICATIONS GAP & FLUSH DIMENSIONS INDEX DESCRIPTION FIGURE STANDARD CAB 1 QUAD CAB 2 PICKUP BOX 3 MEGA CAB 4 NOTE: All measurements are in mm. O/F = Over Flush. U/F = Under Flush. DI

Page 4700 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual NOTE: All measurements are in mm. O/F = Over Flush. U/F = Under Flush. DIMENSION DESCRIPTION GAP FLUSH 7 Quarter to front door 5.0 ± 1.5 Parallel within 1.00.0 ± 1.5 8 Front door to quarter characte

Page 4701 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual NOTE: All measurements are in mm. O/F = Over Flush. U/F = Under Flush. DIMENSION DESCRIPTION GAP FLUSH 1 Tailgate to outer box (Up/Down surface only)— 0.0 ± 1.5 Parallel within 1.0 2 Cab Back to bo

Page 4702 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual NOTE: All measurements are in mm. O/F = Over Flush. U/F = Under Flush. DIMENSION DESCRIPTION GAP FLUSH 1 Bumper To Grille 19.0 ± 4.0 — Fig. 4 MEGA CAB - GAP & FLUSH

Page 4703 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual NOTE: All measurements are in mm. O/F = Over Flush. U/F = Under Flush. DIMENSION DESCRIPTION GAP FLUSH 2 Hood To Grille 1.5 ± 1.0 U/F 0.5 ± 1.75 3 Fender To Hood 6.0 ± 2.0 Parallel Within 1.0U/F 3.

Page 4704 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual OPENING DIMENSIONS SPECIFICATIONS BODY OPENING DIMENSIONS INDEX DESCRIPTION FIGURE WINDSHIELD OPENING 5 DOOR OPENING - STANDARD CAB 6 DOOR OPENINGS - QUAD CAB 7 REAR WINDOW OPENING 8 ENGINE COMPARTMEN
