Page 4033 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: Ignition on. Battery voltage between 9.0 and 16.0 volts. Set Condition: The TIPM detects a short to ground on the Transfer Case Position Sensor Signal circuit for 2.0 seconds. Possible

Page 4034 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.(T103) 5-VOLT SUPPLY CIRCUIT OPEN Turn the ignition off to the lock position. Disconnect the TIPM C4 harness connector. Measure the resistance of the (T103) 5-volt supply circuit between the TIPM C4

Page 4035 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6.(D201) MODE SENSOR A CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (D201) Mode Sensor A circuit. Is the resistance below 5.0 ohms? Ye s>> Repair the (D201) Mode Sensor A ci

Page 4036 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual C1405- TRANSFER CASE RANGE POSITION SENSOR CIRCUIT HIGH For a complete wiring diagramRefer to Section 8W

Page 4037 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With the ignition on. Battery voltage between 9.0 and 16.0 volts Set Condition: The TIPM detects 5.0 volts on the Transfer Case Range Position Sensor Signal circuit for 2.0 seconds whe

Page 4038 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.(D201) MODE SENSOR A CIRCUIT SHORTED TO VOLTAGE Measure the voltage of the (D201) Mode Sensor A circuit. Is the voltage above 5.5 volts? Ye s>> Repair the (D201) Mode Sensor A circuit for a short to

Page 4039 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5.(D201) MODE SENSOR A CIRCUIT OPEN Turn the ignition off to the lock position. Disconnect the TIPM C4 harness connector. Measure the resistance of the (D201) Mode Sensor A circuit between the Shift M

Page 4040 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7.INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. While moni
