Page 633 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0340-CAMSHAFT POSITION (CMP) LOST For a complete wiring diagramRefer to Section 8W.

Page 634 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: While the engine is running. Set Condition: The ECM no longer detects a signal from the Engine Position Sensor. Possible Causes INJECTOR DTC’S PRESENT OTHER DTC’S CAMSHAFT SENSOR (

Page 635 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.CAMSHAFT SENSOR Turn the ignition off. Disconnect the cam sensor harness connector. Check connectors - Clean/repair as necessary. Measure the resistance between the (F855) 5-volt supply circuit and

Page 636 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5.(K916) RETURN CIRCUIT OPEN Measure the resistance of the (K916) return circuit between the ECM harness connector and the cam sensor harness connector. Is the resistance less than 10 ohms? Ye s>> Go

Page 637 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7.(K44) SIGNAL CIRCUIT SHORTED TO (F855) 5-VOLT SUPPLY CIRCUIT Measure the resistance between the (K44) signal circuit and the (F855) 5-volt supply circuit in the sensor harness connector. Is the resi

Page 638 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 10.ECM Reconnect the ECM harness connectors. Measure the voltage between the (K44) signal circuit in the sensor har- ness connector and battery negative. Is the voltage less than 1 volt? Ye s>> Refer

Page 639 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0341-CAMSHAFT POSITION (CMP) SENSOR SIGNAL For a complete wiring diagramRefer to Section 8W.

Page 640 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: While the engine is running. Set Condition: The ECM no longer detects a signal from the Engine Position Sensor. Possible Causes INJECTOR DTC’S PRESENT OTHER DTC’S CAMSHAFT SENSOR (
