Page 4353 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SPECIAL TOOLS BODY Trim Stick C-4755 TORX BIT SET C-4794-B REMOVER, MOLDINGS C-4829-A

Page 4354 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual page page CABLE-CHECK REMOVAL .................................... 18 INSTALLATION ............................... 19 COVER REMOVAL .................................... 20 INSTALLATION ...............

Page 4355 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CABLE-CHECK REMOVAL 1. Open the tailgate and locate the tailgate check cable (3) on the left and right of the cargo box below the tailgate striker (1) as necessary. 2. Pry the cable lock tab(s) (4) ou

Page 4356 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Position the tailgate check cable (2) onto the left and right side of the tailgate (3) as necessary. 2. Install the bolt (1) that secures the small end of the tailgate check cable(s) t

Page 4357 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual COVER REMOVAL 1. Open the tailgate (1) and remove the tailgate liner, if equipped. 2. Remove the ten bolts (2) that secure the tailgate cover (3) to the inside of the tailgate and remove the cover. IN

Page 4358 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual HINGE REMOVAL 1. Remove the tailgate (Refer to 23 - BODY/TAIL- GATE/TAILGATE - REMOVAL). 2. If required, remove the bushing (3) from each tail- gate hinge (1). 3. Remove the two bolts (4)that secure e

Page 4359 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual LATCH REMOVAL 1. Open the tailgate and remove the tailgate liner, if equipped. 2. Remove the ten bolts (5) that secure the tailgate cover (4) to the inside of the tailgate and remove the cover. 3. Usi

Page 4360 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Locate the actuator rod (3) to the control (2) using the reference mark made during the removal pro- cedure and connect the rod to the control. 5. Position the tailgate cover (4) onto the inside of
