DODGE RAM SRT-10 2006 Service Repair Manual 2.(F855) 5-VOLT SUPPLY SHORTED TO VOLTAGE Key off. Disconnect the sensor connectors for each pressure sensor, and the engine position sensor. Disconnect the ECM 50 way harness connector. NOTE: Check c

Page 770 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0698-ACCELERATOR PEDAL POSITION SENSOR (APPS) SUPPLY VOLTAGE TOO LOW

Page 771 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual For a complete wiring diagramRefer to Section 8W. When Monitored: With engine running. Set Condition: Low voltage detected at the APPS supply circuit or low voltage detected at the APPS 1 5–volt sup

Page 772 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2.(F855) 5-VOLT SUPPLY CIRCUIT SHORTED TO OTHER CIRCUITS Measure the resistancebetween the (F855) APPS 1 5-volt supply circuit at the ECM harness connector and all other circuits in the ECM con- necto

Page 773 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4.APPS Reconnect the APPS harness connector. Ignition on, engine not running. Monitor the APPS 1 and APPS 2 voltage with the scan tool while depressing thethrottle pedal. Is the voltage transition sho

Page 774 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0699-ACCELERATOR PEDAL POSITION SENSOR (APPS) SUPPLY VOLTAGE TOO HIGH

Page 775 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual For a complete wiring diagramRefer to Section 8W. When Monitored: Whileengineisrunning. Set Condition: High voltage detected at the APPS supply circuit. Possible Causes (F855) 5-VOLT SUPPLY OPEN (F855

Page 776 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.ECM Turn the ignition off. Reconnect the ECM harness connector(s). Ignition on, engine not running. Measure the voltage between the (F855) APPS #1 5-volt supply circuit at the sensor harness connect
