Page 4593 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual page page BACKLITE REMOVAL ................................... 257 INSTALLATION .............................. 258 BACKLITE VENT GLASS REMOVAL ................................... 261 INSTALLATION ....

Page 4594 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual BACKLITE REMOVAL CAUTION: It is difficult to salvage the backlite dur- ing the removal operation. The backlite is part of the structural support for the roof. The urethane bonding used to secure the g

Page 4595 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. On quad cab models remove the upper c-pillar trim (5) (Refer to 23 - BODY/INTERIOR/C-PILLAR UPPER TRIM - REMOVAL). 5. Bend backlite retaining tab (2) inward against glass. 6. Disconnect the rear wi

Page 4596 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Set glass (1) on lower fence and move glass for- ward into opening. 7. Firmly push glass (1) against rear window glass opening fence. 8. Bend tabs around edges of backlite opening fence to retain g

Page 4597 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 15. Install the headliner (9) (Refer to 23 - BODY/IN- TERIOR/HEADLINER - INSTALLATION).

Page 4598 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual BACKLITE VENT GLASS REMOVAL 1. Slide the upper run channel (1) out of the window frame (2). 2. Slide the vent glass (3) upward to remove from the lower window frame (2). 3. Lower the glass (3) out of

Page 4599 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual WINDSHIELD WARNING WINDSHIELD SAFETY PRECAUTIONS Do not operate the vehicle within 24 hours of windshield installation. It takes at least 24 hours for urethane adhesive to cure. If it is not cured, th

Page 4600 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Remove the a-pillar weatherstrip retainer (1) (Refer to 23 - BODY/WEATHERSTRIP/SEALS/A-PILLAR WEATHERSTRIP RETAINER - REMOVAL). 4. Remove the a-pillar trim panels (2) (Refer to 23 - BODY/INTERIOR/A
