DODGE RAM SRT-10 2006 Service Repair Manual NOTE: The pitman shaft will not clear the housing if it is not centered. 8. Remove the pitman shaft from the gear (1). 9. Remove dust seal from the housing with the seal remover adapter tool 8990 (2).

Page 2458 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Install pitman shaft protective seal protector 8993 (2)overtheshaft. 8. Install the pitman shaft into the steering gear until it fully seats into the bearing. 9. Install the new cover bolts and tig

Page 2459 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual STEERING GEAR INPUT SHAFT SEAL REMOVAL 1. Remove the steering gear from the vehicle(Referto19-STEERING/GEAR-REMOVAL). CAUTION: Do not overtighten the vise on the gear case. This may affect the adjustm

Page 2460 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 10. Remove the valve housing (1) and wormshaft assembly from the steering gear housing and place the valve housing in a soft jawed vise. 11. Remove the retainer ring (3) set screw (1) from the valve h

Page 2461 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 13. Separate the wormshaft assembly from the valve housing, Then remove the wormshaft assembly from the vise. 14. Remove the dust seal (3) with a pick (1). CAUTION: Use care not to score the housing b

Page 2462 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 16. Using slide hammer puller C-3752 (1) with seal remover adapter 8990 (1) remove the oil seal. INSTALLATION 1. Inspect the piston teflon seals for damage. Replace if needed. NOTE: To replace the tef

Page 2463 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Install the input shaft seal protector 8986 (2). 8. Coat the new seal inhigh temp greaseand Install the new oil seal using the input shaft seal installer tool 8987 driver (2) and C-4171 handle (3).

Page 2464 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual PITMAN SHAFT REMOVAL GAS 1. Separate the pitman arm from the gear box (Refer to 19 - STEERING/LINKAGE/PITMAN ARM - REMOVAL). 2. Clean exposed end of pitman shaft (1) and housing with a wire brush. 3.
