INPUT AND PLANETARY GEAR
1. Lubricate gears and thrust washers (5) with recom-
mended transmission fluid.
2. Install first thrust washer in low range gear (4). Be
sure washer tabs are properly aligned in gear
notches.
3. Install input gear (3) in low range gear (4). Be sure
input gear is fully seated.
4. Install remaining thrust washer (5) in low range
gear (4) and on top of input gear (3). Be sure
washer tabs are properly aligned in gear notches.
5. Install retainer (2) on input gear and install snap-
ring (1).
6. Align and install low range/input gear assembly (2)
in front case (1). Be sure low range gear pinions
are engaged in annulus gear and that input gear
shaft is fully seated in front bearing.
7. Install snap-ring (2) to hold input/low range gear (1)
into front bearing.
8. Install a new input gear seal using Seal Installer
8841 and Universal Handle C-4171.
Page 4242 of 5267
SHIFT FORKS AND MAINSHAFT
1. Lubricate mainshaft splines with recommended
transmission fluid.
NOTE: Replace the mode hub retainer if the legs
were distorted during removal.
2. Install the mode hub retainer (1) onto the mode
hub (2).
3. Install the mode hub (2) and mode hub retainer
onto the differential assembly (1). Make sure the
retainer is fully seated onto the differential.
4. Install the differential assembly (1) onto the main-
shaft (2).
Page 4243 of 5267
5. Install the differential snap-ring (1).
6. Install the intermediate clutch shaft (1).
7. Install the clutch shaft thrust ring (1).
Page 4244 of 5267
8. Install clutch shaft (2) snap-ring (1).
9. Lubricate sector shaft with transmission fluid and
install shift sector (1) in case. Position slot in sector
so it will be aligned with shift fork pin when shift
forks are installed.
10. Install the shift sector o-ring.
11. Assemble and install range fork (2) and hub (1).
Be sure hub is properly seated in low range gear
and engaged to the input gear.
12. Align and insert range fork pin in shift sector slot.
Page 4245 of 5267
13. Install the shift rail (1) into the range fork assem-
bly (2) and the front case.
14. Install the mainshaft and differential assembly (2)
into the input gear and transfer case (1).
FRONT OUTPUT SHAFT AND DRIVE CHAIN
1. Install the front output shaft into the front output
shaft bearing.
2. Install the front output shaft snap-ring (2) onto the
output shaft (1).
3. Install the new front output shaft seal with Installer
MB991168A
Page 4246 of 5267
4. Install new o-ring (1) on detent plug (2).
NOTE: Shift the transfer case to the same range/
mode position it was in when the shift motor was
removed prior to installing the shift detent compo-
nents.
5. Install detent plunger (4), spring (3), and plug (2).
Tighten the plug to 16-25 Nꞏm (12-18 ft. lbs.).
6. Install the new front output shaft seal slinger (1)
with Installer 8840 (2). Install the slinger onto the
shaft until the tool contacts the front of the output
shaft.
Page 4247 of 5267
7. Install the front sprocket (1), rear sprocket (3), and
chain (2) as an assembly.
8. Lower the front sprocket, rear sprocket, and chain
over the front and rear output shafts simultaneously
until fully seated on both splines.
9. Install the rear output shaft retaining ring (2) onto
the output shaft (1).
10. Install the front sprocket (1) retaining ring (2).
Page 4248 of 5267
11. Inspect mode fork assembly (1). Replace pads if
necessary. Also check springs and slider bracket.
Replace worn or damaged components.
12. Install the mode fork (2) and sleeve (3) over the
shift rail (1) and mainshaft.
13. Install spring (2) onto the shift rail (1).
