Page 4641 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. If vehicle is aQuad Cab, remove the lower b-pillar trim panel (1) (Refer to 23 - BODY/INTERIOR/B- PILLAR LOWER TRIM - REMOVAL). 4. Separate the front door opening seal (6) from the door opening fla

Page 4642 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual REAR DOOR SEAL 1. Remove the lower b-pillar trim panel (1) (Refer to 23 - BODY/INTERIOR/B-PILLAR LOWER TRIM - REMOVAL). 2. Remove the lower c-pillar trim (1) (Refer to 23 - BODY/INTERIOR/C-PILLAR TRIM

Page 4643 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Separate the rear door opening seal (5) from the door opening flange. INSTALLATION FRONT DOOR SEAL 1. Position the front door seal (6) to the bottom of the door opening, with bulb facing outboard,

Page 4644 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2. If vehicle is aStandard Cab, install the lower b-pil- lar trim (3) (Refer to 23 - BODY/INTERIOR/B-PIL- LAR LOWER TRIM - INSTALLATION). 3. If vehicle is aQuad Cab, install the lower b-pillar trim (1

Page 4645 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Install the cowl trim panel (1) (Refer to 23 - BODY/ INTERIOR/COWL TRIM - INSTALLATION) NOTE: When installing a new weatherstrip on the front door opening, remove the tear strip starting at the spl

Page 4646 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2. Install the lower c-pillar trim (1) (Refer to 23 - BODY/INTERIOR/C-PILLAR TRIM - INSTALLATION). 3. Install the lower b-pillar trim (1) (Refer to 23 - BODY/INTERIOR/B-PILLAR LOWER TRIM - INSTALLATIO

Page 4647 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DRIP RAIL WEATHERSTRIP RETAINER REMOVAL 1. Separate the drip rail weatherstrip (3) from the weatherstrip retainer (1). 2. Remove the seven screws (2) and remove the retainer (1). INSTALLATION 1. Insta

Page 4648 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual FRONT DOOR GLASS RUN WEATHERSTRIP REMOVAL 1. Remove the door glass (Refer to 23 - BODY/ DOOR - FRONT/DOOR GLASS - REMOVAL). 2. Separate the front door glass run weatherstrip (2) out of the door frame
