Page 1833 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 11. Installrockerarms(Referto9-ENGINE/CYLIN- DER HEAD/ROCKER ARM / ADJUSTER ASSY - INSTALLATION). 12. Install timing case cover (figure4) (Refer to 9 - ENGINE/VALVE TIMING/TIMING BELT / CHAIN COVER(S)

Page 1834 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 14. Install cylinder head covers (Refer to 9 - ENGINE/ CYLINDER HEAD/CYLINDER HEAD COVER(S) - INSTALLATION). 15. Install intake manifold (Refer to 9 - ENGINE/MAN- IFOLDS/INTAKE MANIFOLD - INSTALLATION

Page 1835 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 17. Install the generator (2). 18. Install the accessory drive belt. (Refer to 7 - COOLING/ACCESSORY DRIVE/DRIVE BELTS - INSTALLATION). 19. Install the radiator (Refer to 7 - COOLING/EN- GINE/RADIATOR

Page 1836 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CRANKSHAFT REMOVAL 1. Remove the vibration damper (1) (Refer to 9 - ENGINE/ENGINE BLOCK/VIBRATION DAMPER - REMOVAL). 2. Remove the rear oil seal retainer (Refer to 9 - ENGINE/ENGINE BLOCK/CRANKSHAFT R

Page 1837 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Remove the timing chain cover (Refer to 9 - ENGINE/VALVE TIMING/TIMING BELT / CHAIN COVER(S) - REMOVAL). 7. Remove the oil pump (Refer to 9 - ENGINE/LUBRICATION/OIL PUMP - REMOVAL).

Page 1838 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8. Removethetimingdrive(2)(Referto9-ENGINE/ VALVE TIMING/TIMING BELT/CHAIN AND SPROCKETS - REMOVAL). 9. Identify rod bearing caps before removal. Remove rod bearing caps with bearings. 10. Identify ma

Page 1839 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 11. Remove main bearing caps (1) and bearings one at a time. 12. Remove the thrust washers. 13. Remove the crankshaft out of the block.

Page 1840 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Select the proper main bearings (Refer to 9 - ENGINE/ENGINE BLOCK/CRANKSHAFT MAIN BEARINGS - STANDARD PROCEDURE). 2. Install main bearings in block and caps, and lubri- cate bearings.
