Page 2049 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DRB IIIwith PEP Module – OT-CH6010A Pressure Transducer OT-CH7059 Adaptor 8116

Page 2050 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SYSTEM-AIR INTAKE DESCRIPTION Air deflectors mounted to the hood and front grill route the cool incoming air intothe right inner fender (3) where the inlet for the air cleaner housing (4) resides. Air

Page 2051 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual ELEMENT-AIR CLEANER REMOVAL 1. Unclip the air cleaner cove (1) and release the top of the air cleaner housing assembly. 2. Pull the air filter element up and out of the air cleaner housing assembly.

Page 2052 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Install the air filter element (2) into the housing assembly (3). 2. Position the alignment tabs (3) of the housing cover (1) into the lower housing assuring the posi- tion of the inte

Page 2053 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual HOUSING-AIR CLEANER REMOVAL 1. Disconnect the air inlet duct (1) and crankcase ventilation hose from the air cleaner housing (2). 2. Remove the air cleaner housing fastener (6) on the front core suppo

Page 2054 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Position the housing (3) over the guide pins (2) and pushdowntoseat. 2. Install and tighten the housing fasteners (6). 3. Connect the throttle body air inlet duct (1) and crank case ve

Page 2055 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual MOUNTS-ENGINE REMOVAL NOTE: This procedure covers either the left or right engine mount. 1. Raise vehicle on hoist. 2. Support oil pan with suitable jack. 3. Loosen engine mount (1) to block bolts or.

Page 2056 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION NOTE: This procedure covers either the left or right engine mount. 1. With engine raised, position engine mount (2) onto engine and install bolts. Tighten bolts to 41 Nꞏm (30 ft. lbs.)
