Page 3513 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 229: Installing Camshaft Timing Tube Assy Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. b. Align the timing tube knock pin with the knock pin groove of the drive gear, and temporarily install t

Page 3514 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 230: Aligning Timing Tube Knock Pin With Knock Pin Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

Page 3515 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 231: Mounting Hexagon Wrench Head Portion Of Camshaft In Vise Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. e. Align the camshaft knock pin with the knock pin groove of the timing tube, and push

Page 3516 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 232: Installing Bolts Using SST Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 1. Apply engine oil to the cam and gear of the camshaft and also the journal of the cylinder head. 2. Align the ti

Page 3517 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 233: Aligning Timing Marks Of Camshaft Drive And Driven Main Gears Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

Page 3518 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 234: >Applying Seal Packing To Camshaft Housing Plug Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 4. Apply seal packing to the camshaft housing plug. Remove the old packing (FIPG) material.

Page 3519 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 235: Installing Camshaft Housing Plug Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 5. Install the camshaft housing plug to the cylinder head as shown in the illustration. 6. Install the oil c

Page 3520 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 236: Applying Seal Packing To Front Bearing Cap Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 7. Apply seal packing to the front bearing cap. Remove any old packing (FIPG) material and be caref
