Page 1545 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 34: Identifying Clearance Warning ECU Assy Terminals Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE CLEARANCE WARNING ECU ASSY (SEE REPLACE

Page 1546 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 36: Front Right Sensor Wiring Diagram Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. INSPECTION PROCEDURE 1.INSPECT ULTRASONIC SENSOR NO.1 a. Remove ultrasonic sensor No.1. b. Measure the resi

Page 1547 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 37: Identifying Ultrasonic Sensor No.1 Terminals Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. OK: Go To Next Step. 2.CHECK HARNESS AND CONNECTOR (CLEARANCE WARNING ECU ASSY - ULTRASONIC SENSO

Page 1548 of 4500

LEXUS LS430 2003 Factory Repair Manual

Page 1549 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 38: Identifying Clearance Warning ECU Assy Terminals Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE CLEARANCE WARNING ECU ASSY (SEE REPLACE

Page 1550 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 40: Front Right Side Sensor Wiring Diagram Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. INSPECTION PROCEDURE 1.INSPECT ULTRASONIC SENSOR NO.1 a. Remove ultrasonic sensor No.1. b. Measure the

Page 1551 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 41: Identifying Ultrasonic Sensor No.1 Terminals Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. OK: Go To Next Step. 2.CHECK HARNESS AND CONNECTOR (CLEARANCE WARNING ECU ASSY - ULTRASONIC SENSO

Page 1552 of 4500

LEXUS LS430 2003 Factory Repair Manual
