LEXUS LS430 2003 Factory Repair Manual Fig. 95: Identifying Rear Seat Cushion Heater LH Connector Terminals Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. n.INSPECT REAR SEATBACK HEATER ASSY LH a. Measure the resistance between the termin

Page 1730 of 4500

LEXUS LS430 2003 Factory Repair Manual Standard: TESTER CONNECTION AND SPECIFIED CONDITION If the result is not as specified, replace the rear seat cushion heater assy RH. Fig. 97: Identifying Rear Wing Outer Heater RH Connector Termin

Page 1731 of 4500

LEXUS LS430 2003 Factory Repair Manual TESTER CONNECTION AND SPECIFIED CONDITION If the result is not as specified, replace the rear seat cushion heater assy RH. Fig. 98: Identifying Rear Wing Outer Heater RH Connector Terminals Courte

Page 1732 of 4500

LEXUS LS430 2003 Factory Repair Manual If the result is not as specified, replace the rear seat cushion heater assy RH. Tester ConnectionConditionSpecified Condition A1 - B120°C (68°F)4.2 to 5.1 ohms C2 - C420°C (68°F)4.2 to 5.1 ohms

Page 1733 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 99: Identifying Rear Cushion Heater RH Connector Terminals

Page 1734 of 4500

LEXUS LS430 2003 Factory Repair Manual Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. p.INSPECT REAR SEATBACK HEATER ASSY RH a. Measure the resistance between the terminals of the rear seatback heater RH. Standard: TESTER CONNECTION AND

Page 1735 of 4500

LEXUS LS430 2003 Factory Repair Manual REMOVAL AND INSTALLATION OF BATTERY TERMINAL a. Before performing electronic work, disconnect the battery negative (-) terminal cable in order to prevent it from shorting and burning out. b. When

Page 1736 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 1: Disconnecting Battery Negative (-) Terminal Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
