Page 2969 of 4500

LEXUS LS430 2003 Factory Repair Manual

Page 2970 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 28: Identifying Wire Clamps Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. e. Install the engine wire protector (LH side) with the 4 bolts. f. Install the 2 wire clamps on the engine wire (RH si

Page 2971 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 30: Connecting VSV Connector For EVAP Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. Torque: 7.5 N.m (76.5 kgf.cm, 66 in..lbf) k. Install the V-bank cover bracket No. 2 with bolt. Torque: 7.5

Page 2972 of 4500

LEXUS LS430 2003 Factory Repair Manual 16.REFILL ENGINE COOLANT (See ENGINE COOLANT ) 17.CHECK FOR ENGINE COOLANT LEAKS (See ON -VEHICLE INSPECTION ) COMPONENTS

Page 2973 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 31: Identifying Camshaft Timing Oil Control Valve Assy RH Components Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. REPLACEMENT

Page 2974 of 4500

LEXUS LS430 2003 Factory Repair Manual 1.REMOVE V-BANK COVER a. Remove the 2 nuts and V-bank cover. 2.REMOVE AIR CLEANER INLET NO.1 3.REMOVE INTAKE AIR CONNECTOR PIPE a. Disconnect the air hose and ventilation hose. b. Remove the b

Page 2975 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 32: Identifying Camshaft Timing Oil Control Valve Assy LH Components Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. REPLACEMENT

Page 2976 of 4500

LEXUS LS430 2003 Factory Repair Manual 1.REMOVE V-BANK COVER a. Remove the 2 nuts and V-bank cover. 2.REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSY LH a. Disconnect the oil control valve connector. b. Remove the bolts and oil control
