Page 1785 of 4500

LEXUS LS430 2003 Factory Repair Manual WIRING DIAGRAM Fig. 45: Speedometer Wiring Diagram Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. INSPECTION PROCEDURE 1.PERFORM ACTIVE TEST BY HAND-HELD TESTER a. Operate the hand-held tester acc

Page 1786 of 4500

LEXUS LS430 2003 Factory Repair Manual METER: SPEED METER DATA LIST REFERENCE OK: Vehicle speed displayed on the tester is almost the same as the actual vehicle speed. NG: Go to step 3 OK: REPLACE COMBINATION METER ASSY (SEE OVERH

Page 1787 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 46: Identifying Terminals C12-18 Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. e. Check the si gnal waveform according to the condition (s) in the table below.

Page 1788 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 47: Identifying Signal Waveform Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. SIGNAL WAVEFORM CONDITIONS OK: As shown in the illustration HINT: As vehicle speed increases, the cycle of the

Page 1789 of 4500

LEXUS LS430 2003 Factory Repair Manual 5.CHECK HARNESS AND CONNECTOR (ABS & TRACTION ACTUATOR ASSY (VSC) - COMBINATION METER ASSY) (SEE HOW TO PROCEED WITH TROUBLESHOOTING ) a. Disconnect the C12 and S42 connectors. b. Measure the resi

Page 1790 of 4500

LEXUS LS430 2003 Factory Repair Manual

Page 1791 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 48: Identifying C12 And S42 Connectors Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: GO TO NEXT STEP 6.INSPECT ABS & TRACTION ACTUATOR ASSY (VS

Page 1792 of 4500

LEXUS LS430 2003 Factory Repair Manual WIRING DIAGRAM Fig. 50: Tachometer Wiring Diagram Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. INSPECTION PROCEDURE 1.PERFORM ACTIVE TEST BY HAND-HELD TESTER a. Operate the hand-held tester acco
