Page 2289 of 4500

LEXUS LS430 2003 Factory Repair Manual 4.INSPECT COMBINATION SWITCH ASSY (PASSENGER SIDE) a. Measure the resistance of the half latch and full latch switch. TERMINALS RESISTANCE REFERENCE If the result is not as specified, replace the s

Page 2290 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 90: Inspecting Combination Switch Assy (Passenger Side) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

Page 2291 of 4500

LEXUS LS430 2003 Factory Repair Manual b. Measure the resistance of the pawl switch. TERMINALS RESISTANCE REFERENCE If the result is not as specified, replace the switch ass y. Tester ConnectionConditionSpecified Condition 2 - 5Link not

Page 2292 of 4500

LEXUS LS430 2003 Factory Repair Manual

Page 2293 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 91: Inspecting Combination Switch Assy (Passenger Side) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 5.INSPECT DOOR CLOSER MOTOR ASSY (REAR LEFT SIDE) a. Apply battery voltage and check operati

Page 2294 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 92: Inspecting Door Closer Motor Assy (Rear Left Side) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 6.INSPECT COMBINATION SWITCH ASSY (REAR LEFT SIDE) a. Measure the resistance of the half lat

Page 2295 of 4500

LEXUS LS430 2003 Factory Repair Manual TERMINALS RESISTANCE REFERENCE If the result is not as specified, replace the switch ass y. Tester ConnectionConditionSpecified Condition 1 - 5Door openBelow 1 ohms 1 - 5Half latch10 kohms or higher 1

Page 2296 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 93: Inspecting Combination Switch Assy (Rear Left Side) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
