Page 2065 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 25: Installing SST To Rear Differential Carrier Assy Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. b. Install a dial indicator to the rear differential carrier assy. c. Tighten the SST bolt an

Page 2066 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 26: Tightening SST Bolt Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. d. Using snap ring pliers, remove the side gear shaft snap ring on the drive pinion side. HINT: For reassembly purposes, m

Page 2067 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 27: Removing Side Gear Shaft Snap Ring On Drive Pinion Side Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 26.REMOVE REAR DIFFERENTIAL SIDE GEAR SHAFT SNAP RING a. Using SST and a hammer, create

Page 2068 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 28: Creating Clearance Between Side Bearing (Outer Race) On Ring Gear And Side Gear Shaft Snap Ring Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. b. Using snap ring pliers, remove the side gear

Page 2069 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 29: Removing Side Gear Shaft Snap Ring On Ring Gear Side Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 27.REMOVE REAR DIFFERENTIAL CASE BEARING a. Tighten the SST bolt and push out the outer ra

Page 2070 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 30: Removing Outer Race On Ring Gear Side Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 28.REMOVE REAR DIFFERENTIAL CASE BEARING a. Raise the ring gear of the differential case slightly to remo

Page 2071 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 31: Removing Rear Differential Case Bearing Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 29.REMOVE REAR DIFFERENTIAL CASE SUB-ASSY

Page 2072 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 32: Removing Rear Differential Case Sub-Assy Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 30.REMOVE REAR DRIVE PINION NUT a. Using SST and a hammer, loosen the staked part of the nut. SST 099
