Page 3865 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 76: Removing Rear Door Window Frame Molding Front LH Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 4.REMOVE REAR DOOR WEATHERSTRIP NO. 2 LH a. Using a clip remover, remove the clip and weathers

Page 3866 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 77: Removing Rear Door Weatherstrip No. 2 LH Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 5.REMOVE REAR DOOR WINDOW FRAME MOLDING UPPER LH a. Using a drill of less than phis 4 mm (0.16 in.), g

Page 3867 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 78: Removing Rear Door Window Frame Molding Upper LH Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

Page 3868 of 4500

LEXUS LS430 2003 Factory Repair Manual 6.INSTALL REAR DOOR WINDOW FRAME MOLDING UPPER LH a. Using an air riveter or hand riveter with nose piece, strike the 6 rivets into the door window frame to install the molding to the door frame gar

Page 3869 of 4500

LEXUS LS430 2003 Factory Repair Manual

Page 3870 of 4500

LEXUS LS430 2003 Factory Repair Manual

Page 3871 of 4500

LEXUS LS430 2003 Factory Repair Manual REPLACEMENT HINT: The installation procedures are the removal procedures in reverse order. A bolt without torque specification is a standard bolt (see SPECIFIED TORQUE FOR STANDARD BOLTS ). 1.R

Page 3872 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 83: Removing Luggage Compartment Door Garnish Sub-Assy Outside Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. COMPONENTS
