Page 2977 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 33: Identifying ECM Components Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. REPLACEMENT

Page 2978 of 4500

LEXUS LS430 2003 Factory Repair Manual 1.DISCONNECT BATTERY NEGATIVE TERMINAL 2.REMOVE ENGINE ROOM SIDE COVER a. Remove the 3 clips and engine room side cover. 3.REMOVE ECM COVER a. Remove the 3 bolts and ECM cover. 4.REMOVE ECM a

Page 2979 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 34: Removing ECM Gasket Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. a. Peel off the sponge part of the gasket. b.Spray gasket remover or equivalent on the remaining tape of the gasket.

Page 2980 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 35: Spraying Gasket Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. c. Use a cutter knife. to remove the tape of the gasket.

Page 2981 of 4500

LEXUS LS430 2003 Factory Repair Manual Fig. 36: Removing Taping Gasket Using Cutter Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 6.INSTALL ECM GASKET a. Clean the ECM's seal surface to the gasket with non-reside solvent. b. Attach

Page 2982 of 4500

LEXUS LS430 2003 Factory Repair Manual Torque: 5.5 N.m (55 kgf.cm, 48 in..lbf) 8.INSTALL ECM COVER a. Install the ECM cover with the 3 bolts. Torque: 5.0 N.m (51 kgf.cm, 44 in..lbf) 9.INSTALL ENGINE ROOM SIDE COVER a. Install the e

Page 2983 of 4500

LEXUS LS430 2003 Factory Repair Manual <0029004c004a001100030016001a001d000300350048005000520059004c0051004a000300250052004f00570056000f00030031005800570056000300240051004700030024004600460048004f0048005500440057005200550003003300480047004

Page 2984 of 4500

LEXUS LS430 2003 Factory Repair Manual COMPONENTS
