NISSAN X-TRAIL 2003 Service Repair Manual ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
AT-45
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II)
1. Turn on CONSULT-II and touch “ENGINE” for EURO-OBD
detected item

ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
AT-45
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II)
1. Turn on CONSULT-II and touch “ENGINE” for EURO-OBD
detected items or touch “A/T” for TCM self-diagnosis.
If A/T is not displayed, check TCM power supply and ground cir-
cuit. Refer to AT- 9 4 , "
TCM Terminals and Reference Value" . If
result is NG, refer to PG-2, "
POWER SUPPLY ROUTING" .
2. Touch “SELF DIAGNOSIS”.
Display shows malfunction experienced since the last erasing
operation.
CONSULT-II performs “real time diagnosis”.
Also, any malfunction detected while in this mode will be dis-
played at real time.
SELF-DIAGNOSTIC RESULT TEST MODE
SAT014K
SAT987J
Items (CONSULT-II screen terms) Malfunction is detected when... EURO-OBD (DTC)
CAN COMM CIRCUIT
Malfunction is detected in CAN communication line. U1000
VHCL SPEED SEN·A/T
TCM does not receive the proper voltage signal from the sensor.P0720
VHCL SPEED SEN·MTR—
THROTTLE POSI SEN
TCM receives an excessively low or high voltage from this sensor P1705
SHIFT SOLENOID/V A
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.P0750
SHIFT SOLENOID/V B
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.P0755
OVERRUN CLUTCH S/V
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.P1760
T/C CLUTCH SOL/V
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.P0740
ATF TEMP SEN/CIRC
TCM receives an excessively low or high voltage from the sensor.P0710
BATT/FLUID TEMP SEN—
ENGINE SPEED SIG
TCM does not receive the proper voltage signal from the ECM. P0725
A/T 1ST GR FNCTN
A/T cannot be shifted to the 1st gear position even if electrical circuit is
good.P0731*1
A/T 2ND GR FNCTN
A/T cannot be shifted to the 2nd gear position even if electrical circuit is
good.P0732*1
A/T 3RD GR FNCTN
A/T cannot be shifted to the 3rd gear position even if electrical circuit is
good.P0733*1
A/T 4TH GR FNCTN
A/T cannot be shifted to the 4th gear position even if electrical circuit is
good.P0734*1
LINE PRESSURE S/V
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.P0745
CONTROL UNIT (RAM)
TCM memory (RAM) is malfunctioning —
CONTROL UNIT (ROM)
TCM memory (ROM) is malfunctioning —

Page 2082 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual AT-46
[EURO-OBD]
ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION

*1: These malfunctions cannot be displayed by MIL if another malfunction is assigned to lamp MIL.
DATA MONITOR MODE (A/T)
X: Standard, —: N

Page 2083 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
AT-47
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

DTC WORK SUPPORT MODE WITH CONSULT-II
For details, refer to the separate “CONSULT-II Operations Manual”.
CONSUL

Page 2084 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual AT-48
[EURO-OBD]
ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION

3. Turn ignition switch “ON”. (Do not start engine.)
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “A/T”.
If “A/T” is not in

Page 2085 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
AT-49
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

8. Touch “START”.
9. Perform driving test according to “DTC Confirmation Procedure”
in “TROUBLE DIAGNOSIS

Page 2086 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual AT-50
[EURO-OBD]
ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION

If “NG” appears on the screen, malfunction may exist. Go
to “Diagnostic Procedure”.
11. Perform test drive to check gear shift feelin

Page 2087 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
AT-51
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

DTC WORK SUPPORT MODE
DTC work support item Description Check items (Possible cause)
1ST GR FNCTN P0731Following ite

Page 2088 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual AT-52
[EURO-OBD]
ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION

Diagnostic Procedure Without CONSULT-IIECS004QN
EURO-OBD SELF-DIAGNOSTIC PROCEDURE (WITH GST)
Refer to EC-112, "Generic Scan Tool (GST) Functi
