NISSAN X-TRAIL 2003 Service Repair Manual FINAL DRIVE
MT-93
D
E
F
G
H
I
J
K
L
MA
B
MT

2. Remove differential side bearing (clutch housing side) using the
drift and pullers.
3. Remove differential side bearing (transaxle case side) using the

Page 2026 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MT-94
FINAL DRIVE

Bearing
Check for bearing damage and rough rotation. If necessary,
replace with a new one.
CAUTION:
When replacing tapered roller bearing, replace outer and inner
races as a set.

Page 2027 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual FINAL DRIVE
MT-95
D
E
F
G
H
I
J
K
L
MA
B
MT

c. Move side gears up and down to measure end play, and select
thrust washer so that it satisfies the standard value. Refer to MT-
101, "DIFFERENTIAL SIDE

Page 2028 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MT-96
SHIFT CONTROL

SHIFT CONTROLPFP:32982
Inspection (RS5F51A)ECS008CC
Check contact surfaces and sliding area for wear, damage,
bending, etc. If necessary, replace parts.
SHIFT FORK
Check if the

Page 2029 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual SHIFT CONTROL
MT-97
D
E
F
G
H
I
J
K
L
MA
B
MT

Inspection (RS6F51A)ECS008CD
Check contact surfaces and sliding area for wear, damage,
bending, etc. If necessary, replace parts.
SHIFT FORK
Check if

Page 2030 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MT-98
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsECS008CE
TRANSAXLE
Engine QR20DE QR25DE YD22DDTi
Transaxle model RS5F51A RS6F51A
Mode

Page 2031 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
MT-99
D
E
F
G
H
I
J
K
L
MA
B
MT
FINAL GEAR
End PlayECS008CF
Unit: mm (in)
Baulk Ring ClearanceECS00CV4
Unit: mm (in) Remarks Reverse synchronizer Installed
Doubl

Page 2032 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MT-100
SERVICE DATA AND SPECIFICATIONS (SDS)

Available Snap RingsECS008CH
INPUT SHAFT BEARING SPACER
—For RS5F51A Model—
*: Always check with the Parts Department for the latest parts informatio

MT-100
SERVICE DATA AND SPECIFICATIONS (SDS)

Available Snap RingsECS008CH
INPUT SHAFT BEARING SPACER
—For RS5F51A Model—
*: Always check with the Parts Department for the latest parts information.
6TH INPUT GEAR BUSHING
—For RS6F51A Model—
*: Always check with the Parts Department for the latest parts information.
5TH MAIN GEAR
—For RS5F51A Model—
*: Always check with the Parts Department for the latest parts information.
Available C-RingsECS008CI
MAINSHAFT C-RING
*: Always check with the Parts Department for the latest parts information.5th0.95 - 1.4 (0.037 - 0.055) 0.7 (0.028)
6th (For RS6F51A model) 0.95 - 1.4 (0.037 - 0.055) 0.7 (0.028)
Reverse 0.95 - 1.4 (0.037 - 0.055) 0.7 (0.028)Measurement point Standard Limit value
End play0 - 0.1 mm (0 - 0.004 in)
Thickness mm (in) Part number* Thickness mm (in) Part number*
1.71 (0.0673)
1.76 (0.0693)
1.81 (0.0713)
1.86 (0.0732)
1.91 (0.0752)
1.96 (0.0772)32204 8H510
32204 8H511
32204 8H512
32204 8H513
32204 8H514
32204 8H5152.01 (0.0791)
2.06 (0.0811)
2.11 (0.0831)
2.16 (0.0850)
2.21 (0.0870)
2.26 (0.0890)32204 8H516
32204 8H517
32204 8H518
32204 8H519
32204 8H520
32204 8H521
End play0 - 0.1 mm (0 - 0.004 in)
Thickness mm (in) Part number* Thickness mm (in) Part number*
1.76 (0.0693)
1.81 (0.0713)
1.86 (0.0732)
1.91 (0.0752)
1.96 (0.0772)32204 8H511
32204 8H512
32204 8H513
32204 8H514
32204 8H5152.01 (0.0791)
2.06 (0.0811)
2.11 (0.0831)
2.16 (0.0850)
2.21 (0.0870)32204 8H516
32204 8H517
32204 8H518
32204 8H519
32204 8H520
End play0 - 0.1 mm (0 - 0.004 in)
Thickness mm (in) Part number* Thickness mm (in) Part number*
1.85 (0.0728)
1.90 (0.0748)
1.95 (0.0768)
2.00 (0.0787)32204 8H500
32204 8H501
32204 8H502
32204 8H5032.05 (0.0807)
2.10 (0.0827)
2.15 (0.0846)
2.20 (0.0866)32204 8H504
32204 8H505
32204 8H506
32204 8H507
End play0 - 0.06 mm (0 - 0.0024 in)
Thickness mm (in) Part number* Thickness mm (in) Part number*
2.535 (0.0998)
2.565 (0.1010)
2.595 (0.1022)
2.625 (0.1033)
2.655 (0.1045)
2.685 (0.1057)
2.715 (0.1069)
2.745 (0.1081)
2.775 (0.1093)
2.805 (0.1104)32348 8H800
32348 8H801
32348 8H802
32348 8H803
32348 8H804
32348 8H805
32348 8H806
32348 8H807
32348 8H808
32348 8H8092.835 (0.1116)
2.865 (0.1128)
2.895 (0.1140)
2.925 (0.1152)
2.955 (0.1163)
2.985 (0.1175)
3.015 (0.1187)
3.045 (0.1199)
3.075 (0.1211)32348 8H810
32348 8H811
32348 8H812
32348 8H813
32348 8H814
32348 8H815
32348 8H816
32348 8H817
32348 8H818
