NISSAN X-TRAIL 2003 Service Repair Manual NATS (NISSAN ANTI-THEFT SYSTEM) BL-123 C D E F G H J K L MA B BL 4. CHECK GROUND CIRCUIT FOR IMMU 1. Turn ignition OFF. 2. Check harness continuity between NATS IMMU harness connector E109 terminal

Page 3178 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual BL-124 NATS (NISSAN ANTI-THEFT SYSTEM) 7. CHECK COMMUNICATION LINE GROUND SHORT CIRCUIT 1. Turn ignition switch OFF. 2. Check continuity between ECM terminal 88 (Gasoline engine), 112 (Diesel engine

Page 3179 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual NATS (NISSAN ANTI-THEFT SYSTEM) BL-125 C D E F G H J K L MA B BL Diagnostic Procedure 3EIS008F8 Self-diagnostic results: “DIFFERENCE OF KEY” displayed on CONSULT-II screen 1. CONFIRM SELF-DIAGNO

Page 3180 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual BL-126 NATS (NISSAN ANTI-THEFT SYSTEM) Diagnostic Procedure 4EIS008F9 Self-diagnostic results: “CHAIN OF IMMU-KEY” displayed on CONSULT-II screen 1. CONFIRM SELF-DIAGNOSTIC RESULTS Confirm SELF-

Page 3181 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual NATS (NISSAN ANTI-THEFT SYSTEM) BL-127 C D E F G H J K L MA B BL 5. CHECK INTERFACE CIRCUIT 1. Check continuity between NATS IMMU harness connector E109 terminal 2 (PU) and dongle unit harness conne

Page 3182 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual BL-128 NATS (NISSAN ANTI-THEFT SYSTEM) Diagnostic Procedure 6EIS008FB “SECURITY INDICATOR LAMP DOES NOT LIGHT UP” 1. CHECK FUSE Check 10A fuse [No. 28, located in the fuse block (J/B)]. Is 10A f

Page 3183 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual NATS (NISSAN ANTI-THEFT SYSTEM) BL-129 C D E F G H J K L MA B BL 5. CHECK IMMU FUNCTION 1. Connect NATS IMMU connector. 2. Disconnect security indicator lamp connector. 3. Check continuity between N

Page 3184 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual BL-130 NATS (NISSAN ANTI-THEFT SYSTEM) 4. PERFORM INITIALIZATION WITH CONSULT-II Perform initialization with CONSULT-II. For initialization, refer to “CONSULT-II operation manual NATS”. NOTE: If
