NISSAN X-TRAIL 2003 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-237 [YD22DDTi] C D E F G H I J K L MA EM CYLINDER HEAD Unit: mm (in) VA LV E Valve Dimensions Unit: mm (in) Valve Clearance Unit: mm (in) *: Approximately 80

Page 290 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EM-238 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) Available Shims Stamped mark Thickness mm (in) 2.10 2.10 (0.0827) 2.12 2.12 (0.0835) 2.14 2.14 (0.0843) 2.16 2.16 (0.0850) 2.18 2.18 (0.0858)

Page 291 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-239 [YD22DDTi] C D E F G H I J K L MA EM Valve Spring Valve Lifter Unit: mm (in) Valve Guide Unit: mm (in) Valve spring square mm (in) 1.9 (0.075) Free heigh

Page 292 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EM-240 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) Valve Seat Unit: mm (in) Item Standard Service Cylinder head seat recess diameter (D)Intake 30.000 - 30.016 (1.1811 - 1.1817) 30.500 - 30.516

Page 293 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-241 [YD22DDTi] C D E F G H I J K L MA EM CAMSHAFT Unit: mm (in) *: Total indicator reading CYLINDER BLOCK Unit: mm (in) Depth (H)Intake 8.83 - 9.13 (0.3476 -

Page 294 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EM-242 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) PISTON, PISTON RING AND PISTON PIN Available Piston Unit: mm (in) Piston Ring Unit: mm (in) Piston Pin Unit: mm (in) Out-of-round (X − Y) Li

Page 295 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-243 [YD22DDTi] C D E F G H I J K L MA EM CONNECTING ROD Unit: mm (in) *: After installing in connecting rod CRANKSHAFT Unit: mm (in) *: Total indicator readi

Page 296 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EM-244 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) AVAILABLE MAIN BEARING Main bearing Unit: mm (in) Under size Unit: mm (in) AVAILABLE CONNECTING ROD BEARING Connecting Rod Bearing Unit: mm (
