Page 3673 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual STARTING SYSTEM
SC-29
C
D
E
F
G
H
I
J
L
MA
B
SC

InspectionEKS0031L
MAGNETIC SWITCH CHECK
Before starting to check, disconnect the battery cable from the negative terminal.
Disconnect “M” termi

Page 3674 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual SC-30
STARTING SYSTEM

Brush Spring Check
Check brush spring tension with brush spring detached from brush.
Not within the specified values... Replace.
Brush Holder
1. Perform insulation test betwee

Page 3675 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual STARTING SYSTEM
SC-31
C
D
E
F
G
H
I
J
L
MA
B
SC

ARMATURE CHECK
1. Continuity test (between two segments side by side).
No continuity... Replace.
2. Insulation test (between each commutator bar and

Page 3676 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual SC-32
STARTING SYSTEM

5. Check depth of insulating mold from commutator surface.
Less than 0.2 mm (0.008 in)... Undercut to 0.5 to 0.8 mm
(0.020 to 0.031 in).
AssemblyEKS0031M
Apply high-temperatur

Page 3677 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual STARTING SYSTEM
SC-33
C
D
E
F
G
H
I
J
L
MA
B
SC

Movement (YD engine models)
Compare movement “L” in height of pinion when it is pushed out with
magnetic switch energized and when it is pulled ou

Page 3678 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual SC-34
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
BatteryEKS0031Q
StarterEKS0031R
AlternatorEKS0031S
Applied modelQR20, QR25 engine
YD22 engine
Except
for N

Page 3679 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DI-1
DRIVER INFORMATION SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION
A
B
DI

DRIVER INFORMATION SYSTEM
PRECAUTIONS .......................................................... 3
Precautio

DI-1
DRIVER INFORMATION SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION
A
B
DI

DRIVER INFORMATION SYSTEM
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Wiring Diagrams and Trouble Diagnosis .................. 3
COMBINATION METERS ........................................... 4
System Description .................................................. 4
UNIFIED CONTROL METER ................................ 4
HOW TO CHANGE THE DISPLAY FOR ODO/
TRIP METER ........................................................ 4
POWER SUPPLY AND GROUND CIRCUIT ........ 4
WATER TEMPERATURE GAUGE ........................ 4
TACHOMETER ..................................................... 5
SPEEDOMETER ................................................... 5
FUEL GAUGE ....................................................... 5
AMBIENT TEMPERATURE INDICATOR .............. 5
CAN Communication ................................................ 6
CAN Communication Unit ........................................ 6
TYPE 1 .................................................................. 7
TYPE 2 .................................................................. 8
TYPE 3/TYPE4 ..................................................... 9
TYPE 5 ................................................................ 10
Component Parts and Harness Connector Location .... 11
Combination Meter ................................................. 12
CHECK ................................................................ 12
Schematic/LHD Models .......................................... 13
Wiring Diagram — METER —/LHD Models ........... 14
Schematic/RHD Models ......................................... 16
Wiring Diagram — METER —/RHD Models .......... 17
Terminals and Reference Value for Combination
Meter ...................................................................... 19
Meter/Gauges Operation and Odo/Trip Meter ........ 19
SELF-DIAGNOSIS FUNCTION .......................... 19
HOW TO ALTERNATE DIAGNOSIS MODE ....... 19
How to Proceed With Trouble Diagnosis ................ 20
Diagnosis Flow ....................................................... 20
Power Supply and Ground Circuit Inspection ........ 21
Trouble Diagnosis Chart for Symptom ................... 22
DIAGNOSIS RESULTS ....................................... 22
Fuel Level Sensor Inspection [Gasoline Engine Models] ................................................................... 23
FUEL GAUGE ..................................................... 23
LOW-FUEL WARNING LAMP ............................. 23
Fuel Level Sensor Inspection [Diesel Engine Mod-
els] .......................................................................... 24
FUEL GAUGE ..................................................... 24
LOW-FUEL WARNING LAMP ............................. 24
Engine Speed Signal Inspection ............................. 26
Water Temperature Signal Inspection .................... 26
Vehicle Speed Signal Inspection [with ESP] ........... 26
Vehicle Speed Signal Inspection [without ESP] ...... 26
The Fuel Gauge Pointer Fluctuates, Indicator
Wrong Value or Varies ............................................ 27
The Fuel Gauge Does Not Move to FULL position ... 27
Ambient Temperature Inspection [Without Auto A/
C] ............................................................................ 28
Ambient Temperature Inspection [With Auto A/C] ... 29
Electrical Components Inspection .......................... 30
FUEL LEVEL SENSOR UNIT CHECK/GASO-
LINE ENGINE MODELS ..................................... 30
FUEL LEVEL SENSOR UNIT CHECK/DIESEL
ENGINE MODELS .............................................. 30
AMBIENT SENSOR CHECK ............................... 31
Removal and Installation for Combination Meter .... 31
REMOVAL ........................................................... 31
INSTALLATION ................................................... 31
Disassembly and Assembly for Combination Meter ... 32
DISASSEMBLY ................................................... 32
ASSEMBLY ......................................................... 32
WARNING LAMPS .................................................... 33
Schematic ............................................................... 33
Wiring Diagram — WARN —/LHD Models ............. 34
Wiring Diagram — WARN —/RHD Models ............ 42
Electrical Components Inspection .......................... 50
OIL PRESSURE SWITCH CHECK ..................... 50
DIODE CHECK ................................................... 50
A/T INDICATOR ........................................................ 51
Wiring Diagram — AT/IND —/LHD Models ............ 51
Wiring Diagram — AT/IND —/RHD Models ............ 52
A/T Indicator Does Not Illuminate ........................... 53
