PREPARATION
FAX-3
C
E
F
G
H
I
J
K
L
MA
B
FA X
PREPARATIONPFP:00002
Special Service Tools (SST)EDS0005Q
Tool number
Tool nameDescription
KV401 04100
AttachmentRemoving wheel hub and bearing
assembly
ST36230000
Sliding hammerRemoving wheel hub and bearing
assembly
ST30031000
Bearing replacerRemoving inner race on outer side of wheel
bearing
HT7252000
Ball joint removerRemoving tie-rod outer end and lower ball
joint
ST33061000
Drift
a: 28.5 mm (1.122 in) dia.
b: 38.0 mm (1.496 in) dia.Removing inner race on outer side of wheel
bearings
KV38100200
Drift
a: 65 mm (2.65 in) dia.
b: 49 mm (1.93 in) dia.Removing wheel bearing
KV401052S0
Drift set
KV40105210
KV40105220
Drift
a: 75 mm (2.95 in) dia.
b: 62 mm (2.44 in) dia.
KV40105230Installing splash guard
ZZA0804D
ZZA0803D
ZZA0700D
S-NT146
ZZA0969D
ZZA1143D
ZZA1101D
Page 2698 of 4179
FAX-4
PREPARATION
KV40106200
Drift
a: 114.3 mm (4.50 in) dia.
b: 105.3 mm (4.15 in) dia.Removing wheel bearings, installing splash
guards
KV401047S0
Drift set
KV40104710
Drift
a: 76.3 mm (3.004 in) dia.
b: 67.9 mm (2.673 in) dia.
KV40104720-1
KV40104720-2
KV40104730Installing wheel bearings and splash guard
ST30022000
Drift
a: 110 mm (4.33 in) dia.
b: 46 mm (1.81 in) dia.Installing splash guard
KV401053S0
Drift set
KV40105310
Drift
a: 89.1 mm (3.508 in) dia.
b: 80.7 mm (3.177 in) dia.
KV40105320
KV40105330Installing wheel hub
ST35271000
Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.Assembling support bearings
Installing wheel bearing
KV38107800
Protector
a: 29 mm (1.14 in) dia.
KV38105500
Protector
a: 40 mm (1.57 in) dia.Installing drive shaft
KV40101840
Collar
a: 67 mm (2.64 in) dia.
b: 85 mm (3.35 in) dia.Installing sensor rotor Tool number
Tool nameDescription
ZZA0936D
ZZA0808D
ZZA0920D
ZZA0808D
ZZA0837D
ZZA0835D
ZZA1113D
Page 2699 of 4179
PREPARATION
FAX-5
C
E
F
G
H
I
J
K
L
MA
B
FA X
ST17130000
Drift
a: 32 mm (1.26 in) dia.
b: 60 mm (1.57 in) dia.Disassembling support bearing
ST33252000
Drift
a: 82 mm (3.23 in) dia.
b: 60 mm (2.36 in) dia.Assembling support bearing
KV38100500
Drift
a: 80 mm (3.15 in) dia.
b: 60 mm (2.36 in) dia.Installing sensor rotor
ST35271000
Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.Installing wheel bearing
ST35300000
Drift
a: 45.1 mm (1.776 in) dia.
b: 59 mm (2.32 in) dia.Installing wheel hub Tool number
Tool nameDescription
ZZA0836D
ZZA0838D
ZZA0701D
ZZA0814D
ZZA0881D
Page 2700 of 4179
FAX-6
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartEDS00127
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
—
FAX-14—
FAX-7, FA X -11
—
NVH in PR section.
NVH in RFD section.
NVH in RAX and RSU sections.
Refer to FRONT AXLE in this chart.
NVH in WT section.
NVH in WT section.
Refer to DRIVE SHAFT in this chart.
NVH in BR section.
NVH in PS section.
Possible cause and SUSPECTED PARTS
Excessive joint angle
Joint sliding resistance
Imbalance
Improper installation, looseness
Parts interference
PROPELLER SHAFT
DIFFERENTIAL
REAR AXLE AND REAR SUSPENSION
FRONT AXLE
TIRES
ROAD WHEEL
DRIVE SHAFT
BRAKES
STEERING
SymptomDRIVE
SHAFTNoise×× ×××××× ××
Shake×× ×××××××
FRONT
AXLENoise×× ××× ×××××
Shake×××××××××
Vibration×××××××
Shimmy×× ×××××
Judder× × ×× ××
Poor quality ride or handling×× × ××
Page 2701 of 4179

FRONT WHEEL HUB AND KNUCKLE
FAX-7
C
E
F
G
H
I
J
K
L
MA
B
FA X
FRONT WHEEL HUB AND KNUCKLEPFP:40202
On-Vehicle InspectionEDS0005R
Inspect to check that there is no excessive play, cracking, wear, or
other damage to front axle.
Turn front wheels (left/right) and check the play.
Check that no nails or other foreign objects are embedded.
Retighten all axle nuts and bolts to the specified torque.
FRONT WHEEL BEARINGS
With the vehicle raised, inspect the following.
Move wheel hub in the axial direction by hand. Check that there is no looseness of front wheel bearings.
Rotate wheel hub and check that there is no unusual noise or other irregular conditions. If there are any
irregular conditions, replace the wheel bearing.
Removal and InstallationEDS0005S
REMOVAL
1. Remove tyre. Remove brake hose lock plate from strut.
2. Remove brake caliper from steering knuckle. Hang it in a place where it will not interfere with work. Refer
to BR-27, "
FRONT DISC BRAKE" .
CAUTION:
Avoid depressing the brake pedal with brake caliper removed.
3. Remove wheel sensor from steering knuckle. Refer to BRC-116, "
WHEEL SENSORS" .
CAUTION:
Do not pull on wheel sensor harness.
SMA525A
Axial end play : 0.05 mm (0.002 in)
1. Steering knuckle 2. Splash guard 3. Wheel bearing assembly
4. Snap ring 5. Wheel hub 6. Hub bolt
7. Cotter pin
SDIA0131E
Page 2702 of 4179

FAX-8
FRONT WHEEL HUB AND KNUCKLE
4. Remove cotter pin. Use a hub lock nut wrench to remove lock
nut from drive shaft.
5. Remove disc rotor from wheel hub.
6. Remove cotter pin. Use a ball joint remover to remove tie rod
from steering knuckle.
CAUTION:
When using a ball joint remover, install nuts temporarily.
7. Remove steering knuckle from strut.
8. Remove drive shaft from steering knuckle.
9. Remove cotter pin. Use a ball joint remover to remove trans-
verse link from steering knuckle.
CAUTION:
When using a ball joint remover, install nuts temporarily.
INSPECTON AFTER REMOVAL
Check for deformity, cracks and damage on each parts, replace if necessary.
Ball Joint Inspection
Check for boot breakage, axial looseness, and torque of transverse link ball joint. Refer to FSU-10,
"INSPECTION AFTER REMOVAL" .
INSTALLATION
Refer to FAX-7, "Removal and Installation" for tightening torque. Install in the reverse order of removal.
NOTE:
Refer to component parts location and do not reuse non-reusable parts.
Disassembly and AssemblyEDS0005T
DISASSEMBLY
1. Set steering knuckle on bench vise at point where strut is
attached. Use a sliding hammer (SST) and attachment (SST) to
remove wheel hub and bearing assembly from steering knuckle.
CAUTION:
When placing onto vise, be careful not to damage strut
mounting surface of steering knuckle. Use an aluminum
plate or another suitable tool.
2. As shown in the figure, use a puller (suitable tool), drift (SST),
and bearing replacer (SST) to remove inner race of outer wheel
bearing from wheel hub.
3. Use a flat-bladed screwdriver or similar tool to remove snap ring.
CAUTION:
Be careful not to scratch the steering knuckle.
4. Fix steering knuckle to bench vise. Use a flat-bladed screwdriver
and hammer to remove splash guard from steering knuckle.
SFA649A
FAC0104D
SDIA0588E
Page 2703 of 4179

FRONT WHEEL HUB AND KNUCKLE
FAX-9
C
E
F
G
H
I
J
K
L
MA
B
FA X
5. Use a drift (SST) and a press to remove wheel bearing.
INSPECTION AFTER DISASSEMBLY
Wheel Hub
Check wheel bearings for damage, seizure, and corrosion. Also check wheel hubs for cracks (using a die
test or other method). Replace if any irregular conditions are found.
Steering Knuckle
Check steering knuckle for deformation, cracks, and other damage. Replace if any irregular conditions are
found.
Snap Ring
Check snap ring for wear or other damage. Replace if any irregular conditions are found.
ASSEMBLY
1. Use a drift (SST) to install splash guard onto steering knuckle.
CAUTION:
Discard the old splash guard; replace with a new one.
Install splash guard in position shown in the figure.
2. Use a drift (SST) and a press to press-fit wheel bearing onto
steering knuckle.
CAUTION:
Discard the old wheel bearing; replace with a new one.
3. Install snap ring onto steering knuckle.
SDIA0589E
FAC1217D
SDIA0590E
SDIA0591E
Page 2704 of 4179

FAX-10
FRONT WHEEL HUB AND KNUCKLE
4. Use a drift (SST) and a press to install wheel hub.
5. As shown in the figure, apply a load of 34,324 – 49,033 N
(3500 – 5,000 kg, 7718 – 11,025 lb). Rotate in forward and
reverse directions 10 times each to ensure a good fit.
6. At a rotation speed of 10±2 rpm, place a spring balance at the
point where strut is joined (upper-side bolt hole). Measure rotat-
ing torque. Refer to FA X - 1 9 , "
Wheel Bearing" .
NOTE:
If a load of 34,300 – 49,033 N (3,500 – 5,000 kg, 7718 – 11,025 lb) cannot be applied, carry out the fol-
lowing actions.
Assemble drive shaft and tighten wheel hub lock nuts to specified torque. Then rotate in forward and
reverse direction 10 times each to ensure a good fit.
At a rotation speed of 10±2 rpm, place a spring balance on hub bolt to measure torque. Rotating torque : 1.645 N·m (0.17 kg-m, 15 in-lb) or
less
Spring balance
reading: 10.6 N (1.1 kg, 2.4 lb) or less
Rotation torque : 2.215 N·m (0.22 kg-m, 19 in-lb) or less
Spring balance reading : 37.2 N (3.8 kg, 8.4 lb) or less
SDIA0592E
