2003 NISSAN X-TRAIL Service Repair Manual

fuse chart service indicator wheel size child restraint open gas tank water pump

Page 2577 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TF-1
TRANSFER
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION
A
B
TF

TRANSFER
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint

TF-1
TRANSFER
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION
A
B
TF

TRANSFER
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions .............................................................. 3
Service Notice .......................................................... 4
Wiring Diagrams and Trouble Diagnosis .................. 4
PREPARATION ........................................................... 5
Special Service Tools ............................................... 5
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 8
NVH Troubleshooting Chart ..................................... 8
TRANSFER OIL .......................................................... 9
Replacement ............................................................ 9
DRAINING ............................................................. 9
FILLING ................................................................. 9
Inspection ................................................................. 9
OIL LEAKAGE AND OIL LEVEL ........................... 9
ALL MODE 4X4 SYSTEM ........................................ 10
Power Transfer Diagram ........................................ 10
System Description ................................................ 10
ELECTRIC CONTROLLED COUPLING ............. 10
4WD CONTROL UNIT ........................................ 10
4WD MODE SWITCH .......................................... 11
4WD INDICATOR LAMP AND LOCK INDICATOR
LAMP ................................................................... 11
4WD WARNING LAMP ........................................ 11
System Diagram ..................................................... 12
COMPONENTS FUNCTION DESCRIPTION ..... 13
CAN Communication .............................................. 13
SYSTEM DESCRIPTION .................................... 13
CAN COMMUNICATION UNIT (M/T MODELS
WITHOUT ESP) .................................................. 13
CAN COMMUNICATION UNIT (A/T MODELS
WITHOUT ESP) .................................................. 14
CAN COMMUNICATION UNIT (M/T MODELS
WITH ESP) .......................................................... 15
CAN COMMUNICATION UNIT (A/T MODELS
WITH ESP) .......................................................... 16
TROUBLE DIAGNOSIS ............................................ 18Fail-safe Function ................................................... 18
How to Perform Trouble Diagnosis ......................... 18
BASIC CONCEPT ............................................... 18
Location of Electrical Parts ..................................... 19
Circuit Diagram ....................................................... 20
Wiring Diagram — 4WD — ..................................... 21
LHD MODELS ..................................................... 21
RHD MODELS .................................................... 24
Trouble Diagnosis Chart for Symptoms .................. 27
4WD Control Unit Input/Output Signal Reference
Values ..................................................................... 28
4WD CONTROL UNIT INSPECTION TABLE ..... 28
CONSULT-II Function ............................................. 29
FUNCTION .......................................................... 29
CONSULT-II SETTING PROCEDURE ................ 29
SELF-DIAG RESULT MODE ............................... 30
DATA MONITOR MODE ...................................... 31
ACTIVE TEST MODE ......................................... 32
4WD CONTROL UNIT PART NUMBER .............. 32
TROUBLE DIAGNOSIS FOR SYSTEM .................... 33
Power Supply Circuit for 4WD Control Unit ............ 33
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 33
DIAGNOSTIC PROCEDURE .............................. 33
4WD Control Unit .................................................... 34
DIAGNOSTIC PROCEDURE .............................. 34
ABS System ........................................................... 34
DIAGNOSTIC PROCEDURE .............................. 34
4WD Solenoid ......................................................... 36
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 36
DIAGNOSTIC PROCEDURE .............................. 36
COMPONENT INSPECTION .............................. 38
4WD Actuator Relay ............................................... 38
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 38
DIAGNOSTIC PROCEDURE .............................. 38
4WD Mode Switch .................................................. 40
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 40

Page 2578 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TF-2 DIAGNOSTIC PROCEDURE .............................. 40
COMPONENT INSPECTION .............................. 42
Engine Control Signal ............................................. 42
DIAGNOSTIC

TF-2 DIAGNOSTIC PROCEDURE .............................. 40
COMPONENT INSPECTION .............................. 42
Engine Control Signal ............................................. 42
DIAGNOSTIC PROCEDURE .............................. 42
CAN Communication Line ...................................... 43
DIAGNOSTIC PROCEDURE .............................. 43
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 44
4WD Indicator Lamp and LOCK Indicator Lamp Do
Not Turn ON for Approx. 1 Second When The Igni-
tion Switch Is Turned to ON .................................... 44
DIAGNOSTIC PROCEDURE .............................. 44
4WD Warning Lamp Does Not Turn ON When The
Ignition Switch Is Turned to ON .............................. 45
DIAGNOSTIC PROCEDURE .............................. 45
4WD Warning Lamp Does Not Turn OFF Several
Seconds after Engine Started ................................. 46
DIAGNOSTIC PROCEDURE .............................. 46
4WD Mode Cannot Be Switched after Engine Is
Started .................................................................... 47
DIAGNOSTIC PROCEDURE .............................. 47
Heavy Tight-corner Braking Symptom Occurs
When The Vehicle Is Driven in AUTO Mode and The
Steering Wheel Is Turned Fully to Either Side after
The Engine Is Started ............................................. 48
DIAGNOSTIC PROCEDURE .............................. 48
Vehicle Does Not Enter 4WD Mode Even Though
4WD Warning Lamp Turned to OFF ....................... 49
DIAGNOSTIC PROCEDURE .............................. 50
While Driving, 4WD Warning Lamp Flashes Rapidly
(When Flashing in Approx. 1 Minute and Then Turn-
ing OFF) ................................................................. 50
While Driving, 4WD Warning Lamp Flashes Slowly
(When Continuing to Flash until Turning Ignition Switch OFF) ............................................................ 51
DIAGNOSTIC PROCEDURE ............................... 51
4WD CONTROL UNIT ............................................... 52
Removal and Installation ......................................... 52
REMOVAL ............................................................ 52
INSTALLATION .................................................... 52
SIDE OIL SEAL ......................................................... 53
Removal and Installation ......................................... 53
REMOVAL ............................................................ 53
INSTALLATION .................................................... 53
AIR BREATHER HOSE ............................................. 54
Components ............................................................ 54
Removal and Installation ......................................... 54
TRANSFER ASSEMBLY ........................................... 55
Removal and Installation ......................................... 55
COMPONENTS ................................................... 55
REMOVAL ............................................................ 55
INSTALLATION .................................................... 56
Disassembly and Assembly .................................... 57
COMPONENTS ................................................... 57
ASSEMBLY INSPECTION ................................... 58
DISASSEMBLY .................................................... 62
INSPECTION AFTER DISASSEMBLY ................ 66
SELECTING ADJUSTING SHIMS ....................... 67
ASSEMBLY .......................................................... 68
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 74
General Specifications ............................................ 74
Inspection and Adjustment ...................................... 74
PRELOAD TORQUE BEFORE DISASSEMBLY ... 74
PRELOAD TORQUE AFTER DISASSEMBLY
AND REASSEMBLY ............................................ 74
BACKLASH .......................................................... 74
COMPANION FLANGE RUNOUT ....................... 74
SELECTIVE PARTS ............................................ 74

Page 2579 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual PRECAUTIONS
TF-3
C
E
F
G
H
I
J
K
L
MA
B
TF

PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EDS001W1
The Supplemental Restrai

Page 2580 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TF-4
PRECAUTIONS

Service NoticeEDS001V7
After overhaul refill the transfer with new transfer oil.
Check the oil level or replace the oil only with the vehicle parked on level ground.
During remov

TF-4
PRECAUTIONS

Service NoticeEDS001V7
After overhaul refill the transfer with new transfer oil.
Check the oil level or replace the oil only with the vehicle parked on level ground.
During removal or installation, keep inside of transfer clear of dust or dirt.
Replace all tires at the same time. Always use tires of the proper size and the same brand and pattern.
Fitting improper size and unusual wear tires applies excessive force to vehicle mechanism and can cause
longitudinal vibration.
Disassembly should be done in a clean work area.
Before proceeding with disassembly, thoroughly clean the transfer. It is important to prevent the internal
parts from becoming contaminated by dirt or other foreign matter.
Check for the correct installation status prior to removal or disassembly. If matching marks are required,
be certain they do not interfere with the function of the parts when applied.
All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or
reassembly.
Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace them
with a new ones if necessary.
Gaskets, seals, O-rings and lock nuts should be replaced any time when the transfer is disassembled.
In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If
tightening sequence is specified, use it.
Observe the specified torque when assembling.
Clean and flush the parts sufficiently and blow-dry them.
Be careful not to damage sliding surfaces and mating surfaces.
Use lint-free cloth or towels for wiping parts clean. Common shop rags can leave fibers that could interfere
with the operation of the transfer.
Wiring Diagrams and Trouble DiagnosisEDS001V8
When reading wiring diagrams, refer to the following:
GI-14, "How to Read Wiring Diagrams".
PG-2, "POWER SUPPLY ROUTING".
When performing trouble diagnosis, refer to the following:
GI-10, "How to Follow Trouble Diagnoses".
GI-23, "How to Perform Efficient Diagnosis for an Electrical Incident".

Page 2581 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual PREPARATION
TF-5
C
E
F
G
H
I
J
K
L
MA
B
TF

PREPARATIONPFP:00002
Special Service ToolsEDS0004P
Tool number
Tool nameDescription
KV38101700
Drift
a: 82 mm (3.23 in) dia.
b: 78 mm (3.07 in) dia.Install

Page 2582 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TF-6
PREPARATION

ST30720000
Drift
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.Installing gear ring bearing outer race
(transfer case side)
Installing gear ring bearing inner race
(transfer

Page 2583 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual PREPARATION
TF-7
C
E
F
G
H
I
J
K
L
MA
B
TF

KV38100300
Drift
a: 54 mm (2.13 in) dia.
b: 46 mm (1.81 in) dia.
c: 32 mm (1.26 in) dia.Installing pinion rear bearing outer race
ST33400001
Drift
a: 60 mm

Page 2584 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TF-8
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartEDS001V9
Use the chart below to help you find the cau
