Page 3329 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual LICENSE LAMP FINISHER EI-31 C D E F G H J K L MA B EI LICENSE LAMP FINISHERPFP:84810 Removal and InstallationEIS001NV REMOVAL 1. Remove back door finisher. Refer to EI-34, "Removal and Installation"

Page 3330 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EI-32 DOOR FINISHER DOOR FINISHERPFP:80900 Removal and InstallationEIS000N9 FRONT AND REAR Removal 1. Insert a screwdriver, wrapped with a cloth, into door trim cutout on the inside handle escutcheo

Page 3331 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DOOR FINISHER EI-33 C D E F G H J K L MA B EI 2. Insert a screwdriver, wrapped with a cloth, into the cutout on the front edge of power window switch finisher. Unfasten the metal clip on the front s

Page 3332 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EI-34 BACK DOOR TRIM BACK DOOR TRIMPFP:90900 Removal and InstallationEIS000NA REMOVAL 1. Remove clips of back door trim. 2. Remove back door trim. INSTALLATION Installation is in the reverse order o

Page 3333 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual BODY SIDE TRIM EI-35 C D E F G H J K L MA B EI BODY SIDE TRIMPFP:76913 Removal and InstallationEIS000NB PIIB0591E 1. Front pillar garnish 2. Dashboard side finisher 3. Front body side welt 4. Front

Page 3334 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EI-36 BODY SIDE TRIM CENTER PILLAR LOWER GARNISH Removal Remove front and rear kick panels. Installation Installation is in the reverse order of removal. CENTER PILLAR UPPER GARNISH Removal 1. Remov

Page 3335 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual BODY SIDE TRIM EI-37 C D E F G H J K L MA B EI NOTE: Insert a screwdriver, wrapped with a cloth, into the part shown by an arrow (between the body side panel and clips). Remove clips. When install

Page 3336 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EI-38 FLOOR TRIM FLOOR TRIMPFP:74902 Removal and InstallationEIS000NC REMOVAL 1. Remove front seat and rear seat cushions. Refer to SE-26, "Removal and Installation" and SE-33, "Removal and Install
