NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-277
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

TROUBLE DIAGNOSIS — GENERAL DESCRIPTIONPFP:00000
Symptom ChartECS004VV
Numbers are arranged in order of

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-277
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

TROUBLE DIAGNOSIS — GENERAL DESCRIPTIONPFP:00000
Symptom ChartECS004VV
Numbers are arranged in order of inspection.
Perform inspections starting with number one and work up.
Symptom Condition Diagnostic Item Reference Page
Engine cannot start in “P” and “N”
positions.
AT- 2 9 3
ON vehicle1. Ignition switch and starterPG-2
,
SC-21

2. Control cable adjustmentAT- 4 0 9
3. PNP switchAT- 3 2 4
Engine starts in position other than
“N” and “P” positions.
AT- 2 9 3
ON vehicle1. Control cable adjustmentAT- 4 0 92. PNP switchAT- 3 2 4
Transaxle noise in “P” and “N” posi-
tions.ON vehicle1. Fluid levelAT- 2 5 6
2. Line pressure testAT- 2 6 0
3. Accelerator pedal position (APP) sensorAT- 3 4 5
4. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 3 3 2,
AT- 3 3 9
OFF vehicle5. Oil pumpAT- 4 4 36. Torque converterAT- 4 2 3
Vehicle moves when changing into “P”
position, or parking gear does not dis-
engage when shifted out of “P” posi-
tion.
AT- 2 9 4ON vehicle 1. Control cable adjustmentAT- 4 0 9
OFF vehicle 2. Parking componentsAT- 4 1 6,
AT- 4 4 0
Vehicle runs in “N” position.
AT- 2 9 5
ON vehicle 1. Control cable adjustmentAT- 4 0 9
OFF vehicle2. Forward clutchAT- 4 7 53. Reverse clutchAT- 4 6 4
4. Overrun clutchAT- 4 7 5
Vehicle will not run in “R” position (but
runs in “D”, “2” and “1” positions).
Clutch slips.
Very poor acceleration.
AT- 2 9 7
ON vehicle1. Control cable adjustmentAT- 4 0 9
2. Stall testAT- 2 5 7
3. Line pressure testAT- 2 6 0
4. Line pressure solenoid valveAT- 3 8 7
5. Control valve assemblyAT- 4 0 4
Vehicle will not run in “R” position (but
runs in “D”, “2” and “1” positions).
Clutch slips.
Very poor acceleration.
AT- 2 9 7
OFF vehicle6. Reverse clutchAT- 4 6 4
7. High clutchAT- 4 6 9
8. Forward clutchAT- 4 7 5
9. Overrun clutchAT- 4 7 5
10. Low & reverse brakeAT- 4 8 3
Vehicle braked when shifting into “R”
position.ON vehicle1. Fluid levelAT- 2 5 6
2. Line pressure testAT- 2 6 0
3. Line pressure solenoid valveAT- 3 8 7
4. Control valve assemblyAT- 4 0 4
OFF vehicle5. High clutchAT- 4 6 96. Brake bandAT- 4 9 7
7. Forward clutchAT- 4 7 5
8. Overrun clutchAT- 4 7 5

Page 2314 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual AT-278
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION

Sharp shock in shifting from “N” to “D”
position.ON vehicle1. Engine idling rpmEC-506
2. Accelerator pedal position (APP) s

Page 2315 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-279
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

No creep at all.
AT- 2 9 7
and AT-299
ON vehicle1. Fluid levelAT- 2 5 62. Line pressure testAT- 3 8 7
3.

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-279
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

No creep at all.
AT- 2 9 7
and AT-299
ON vehicle1. Fluid levelAT- 2 5 62. Line pressure testAT- 3 8 7
3. Control valve assemblyAT- 4 0 4
OFF vehicle4. Forward clutchAT- 4 7 55. Oil pumpAT- 4 4 3
6. Torque converterAT- 4 2 3
Failure to change gear from “D1 ” to
“D
2 ”.ON vehicle1. Control cable adjustmentAT- 4 0 9
2. Shift solenoid valve AAT- 3 5 0
3. Control valve assemblyAT- 4 0 4
4. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 3 3 2, AT-339
5. Accelerator pedal position (APP) sensorAT- 3 4 5
OFF vehicle 6. Brake bandAT- 4 9 7
Failure to change gear from “D2 ” to
“D
3 ”.ON vehicle1. Control cable adjustmentAT- 4 0 9
2. Shift solenoid valve BAT- 3 5 6
3. Control valve assemblyAT- 4 0 4
4. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 3 3 2, AT-339
5. Accelerator pedal position (APP) sensorAT- 3 4 5
OFF vehicle6. High clutchAT- 4 6 97. Brake bandAT- 4 9 7
Failure to change gear from “D3 ” to
“D
4 ”.ON vehicle1. PNP switchAT- 3 2 4
2. Overrun clutch solenoid valveAT- 3 6 2
3. Shift solenoid valve AAT- 3 5 0
4. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 3 3 2, AT-339
5. A/T fluid temp sen circ and TCM pow
sourAT- 3 7 4
OFF vehicle 6. Brake bandAT- 4 9 7
Too high a gear change point from “D1
” to “D
2 ”, from “D2 ” to “D3 ”, from “D3
” to “D
4 ”.
AT- 3 0 4
and AT-309
ON vehicle1. Accelerator pedal position (APP) sensorAT- 3 4 5
2. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 3 3 2, AT-339
3. Shift solenoid valve AAT- 3 5 0
4. Shift solenoid valve BAT- 3 5 6
Gear change directly from “D1 ” to “D3
” occurs.ON vehicle1. Fluid levelAT- 2 5 62. Accumulator servo releaseAT- 4 0 4
OFF vehicle 3. Brake bandAT- 4 9 7
Engine stops when shifting lever into
“R”, “D”, “2” and “1”.ON vehicle1. Engine idling rpmEC-506
2. Fluid levelAT- 2 5 6
3. Torque converter clutch solenoid valveAT- 3 6 8
4. Control valve assemblyAT- 4 0 4
OFF vehicle 5. Torque converterAT- 4 2 3
Symptom Condition Diagnostic Item Reference Page

Page 2316 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual AT-280
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION

Too sharp a shock in change from “D1
” to “D
2 ”.ON vehicle1. Accelerator pedal position (APP) sensorAT-345
2. Line pressur

AT-280
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION

Too sharp a shock in change from “D1
” to “D
2 ”.ON vehicle1. Accelerator pedal position (APP) sensorAT-345
2. Line pressure testAT-260
3. Accumulator servo releaseAT-404
4. Control valve assemblyAT-404
5. A/T fluid temp sen circ and TCM pow
sourAT-374
OFF vehicle 6. Brake bandAT-497
Too sharp a shock in change from “D2
” to “D
3 ”.ON vehicle1. Accelerator pedal position (APP) sensorAT-345
2. Line pressure testAT-260
3. Control valve assemblyAT-404
4. A/T fluid temp sen circ and TCM pow
sourAT-374
OFF vehicle5. High clutchAT-4696. Brake bandAT-497
Too sharp a shock in change from “D3
” to “D
4 ”.ON vehicle1. Accelerator pedal position (APP) sensorAT-345
2. Line pressure testAT-260
3. Control valve assemblyAT-404
4. A/T fluid temp sen circ and TCM pow
sourAT-374
OFF vehicle5. Brake bandAT-4976. Overrun clutchAT-475
7. Forward one-way clutchAT-416
Almost no shock or clutches slipping
in change from “D
1 ” to “D2 ”.ON vehicle1. Fluid levelAT-256
2. Accelerator pedal position (APP) sensorAT-345
3. Line pressure testAT-260
4. Accumulator servo releaseAT-404
5. Control valve assemblyAT-404
OFF vehicle 6. Brake bandAT-497
Almost no shock or slipping in change
from “D
2 ” to “D3 ”.ON vehicle1. Fluid levelAT-256
2. Accelerator pedal position (APP) sensorAT-345
3. Line pressure testAT-260
4. Control valve assemblyAT-404
OFF vehicle5. High clutchAT-4696. Brake bandAT-497
Almost no shock or slipping in change
from “D
3 ” to “D4 ”.ON vehicle1. Fluid levelAT-256
2. Accelerator pedal position (APP) sensorAT-345
3. Line pressure testAT-260
4. Control valve assemblyAT-404
OFF vehicle 5. Brake bandAT-497
Vehicle braked by gear change from
“D
1 ” to “D2 ”.ON vehicle 1. Fluid levelAT-256OFF vehicle2. Reverse clutchAT-464
3. Low & reverse brakeAT-483
4. High clutchAT-469
5. Low one-way clutchAT-416,
AT-423
Symptom Condition Diagnostic Item Reference Page

Page 2317 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-281
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

Vehicle braked by gear change from
“D
2 ” to “D3 ”.ON vehicle 1. Fluid levelAT- 2 5 6OFF vehicle

Page 2318 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual AT-282
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION

Gear change shock felt during decel-
eration by releasing accelerator pedal.ON vehicle1. Accelerator pedal position (APP) sensorAT-3

AT-282
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION

Gear change shock felt during decel-
eration by releasing accelerator pedal.ON vehicle1. Accelerator pedal position (APP) sensorAT-3452. Line pressure testAT-260
3. Overrun clutch solenoid valveAT-362
4. Control valve assemblyAT-404
Too high a change point from “D4 ” to
“D
3 ”, from “D3 ” to “D2 ”, from “D2 ” to
“D
1 ”.ON vehicle1. Accelerator pedal position (APP) sensorAT-3452. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT-332, AT-339
Kickdown does not operate when
depressing pedal in “D
4 ” within kick
down vehicle speed.ON vehicle1. Accelerator pedal position (APP) sensorAT-345
2. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT-332, AT-339
3. Shift solenoid valve AAT-350
4. Shift solenoid valve BAT-356
Kickdown operates or engine over-
runs when depressing pedal in “D
4 ”
beyond kick down vehicle speed limit.ON vehicle1. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT-332
, AT-339
2. Accelerator pedal position (APP) sensorAT-345
3. Shift solenoid valve AAT-350
4. Shift solenoid valve BAT-356
Races extremely fast or slips in
changing from “D
4 ” to “D3 ” when
depressing pedal.ON vehicle1. Fluid levelAT-256
2. Accelerator pedal position (APP) sensorAT-345
3. Line pressure testAT-260
4. Line pressure solenoid valveAT-387
5. Shift solenoid valve AAT-350
6. Control valve assemblyAT-404
OFF vehicle7. Brake bandAT-4978. Forward clutchAT-475
Races extremely fast or slips in
changing from “D
4 ” to “D2 ” when
depressing pedal.ON vehicle1. Fluid levelAT-256
2. Accelerator pedal position (APP) sensorAT-345
3. Line pressure testAT-260
4. Line pressure solenoid valveAT-387
5. Shift solenoid valve AAT-350
6. Shift solenoid valve BAT-356
7. Control valve assemblyAT-404
OFF vehicle8. Brake bandAT-4979. High clutchAT-469
10. Forward clutchAT-475
Races extremely fast or slips in
changing from “D
3 ” to “D2 ” when
depressing pedal.ON vehicle1. Fluid levelAT-256
2. Accelerator pedal position (APP) sensorAT-345
3. Line pressure testAT-260
4. Line pressure solenoid valveAT-387
5. Control valve assemblyAT-404
6. Shift solenoid valve BAT-356
OFF vehicle7. Brake bandAT-4978. High clutchAT-469
Symptom Condition Diagnostic Item Reference Page

Page 2319 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-283
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
Races extremely fast or slips in
changing from “D
4 ” or “D3 ” to “D1 ”
when depressing pedal

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-283
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
Races extremely fast or slips in
changing from “D
4 ” or “D3 ” to “D1 ”
when depressing pedal.ON vehicle1. Fluid levelAT- 2 5 6
2. Accelerator pedal position (APP) sensorAT- 3 4 5
3. Line pressure testAT- 2 6 0
4. Line pressure solenoid valveAT- 3 8 7
5. Shift solenoid valve AAT- 3 5 0
6. Shift solenoid valve BAT- 3 5 6
7. Control valve assemblyAT- 4 0 4
OFF vehicle8. Forward clutchAT- 4 7 59. Forward one-way clutchAT- 4 1 6
10. Low one-way clutchAT- 4 1 6,
AT- 4 2 3
Vehicle will not run in any position.ON vehicle1. Fluid levelAT- 2 5 6
2. Control cable adjustmentAT- 4 0 9
3. Line pressure testAT- 2 6 0
4. Line pressure solenoid valveAT- 3 8 7
OFF vehicle5. Oil pumpAT- 4 4 36. Torque converterAT- 4 2 3
7. Parking componentsAT- 4 1 6
Transmission noise in “D”, “2”, “1” and
“R” positions.ON vehicle 1. Fluid levelAT- 2 5 6
OFF vehicle 2. Torque converterAT- 4 2 3
Failure to change from “D3 ” to “22 ”
when changing lever into “2” position.
AT- 3 1 9ON vehicle1. Accelerator pedal position (APP) sensorAT- 3 4 52. Shift solenoid valve BAT- 3 5 6
3. Control valve assemblyAT- 4 0 4
4. Control cable adjustmentAT- 4 0 9
OFF vehicle 5. Brake bandAT- 4 9 7
Gear change from “22 ” to “23 ” in “2”
position.ON vehicle1. PNP switchAT- 3 2 4
2. Control cable adjustmentAT- 4 0 9
Engine brake does not operate in “1”
position.
AT- 3 1 7ON vehicle1. PNP switchAT- 3 2 4
2. Control cable adjustmentAT- 4 0 9
3. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 3 3 2, AT-339
4. Control valve assemblyAT- 4 0 4
5. Overrun clutch solenoid valveAT- 3 6 2
OFF vehicle6. Overrun clutchAT- 4 7 57. Low & reverse brakeAT- 4 8 3
Gear change from “11 ” to “12 ” in “1”
position.ON vehicle1. PNP switchAT- 3 2 4
2. Control cable adjustmentAT- 4 0 9
Does not change from “12 ” to “11 ” in
“1” position.ON vehicle1. PNP switchAT- 3 2 4
2. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 3 3 2, AT-339
3. Shift solenoid valve AAT- 3 5 0
4. Control valve assemblyAT- 4 0 4
OFF vehicle5. Low one-way clutchAT- 4 1 6
,
AT- 4 2 3
6. Brake bandAT- 4 9 7
7. Low & reverse brakeAT- 4 8 3
Symptom Condition Diagnostic Item Reference Page

Page 2320 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual AT-284
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION

Large shock changing from “12 ” to “11
” in “1” position.ON vehicle 1. Control valve assemblyAT-404
OFF vehicle 2. Low

Load next 8 pages

Page: < prev 1-10 ... 2281-2288 2289-2296 2297-2304 2305-2312 2313-2320 2321-2328 2329-2336 2337-2344 2345-2352 ... 4184 next >

check engine light oil pressure gearbox ESP inoperative technical specifications windshield wipers
