Page 3593 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual ENGINE MAINTENANCE (YD22DDTI) MA-33 C D E F G H I J K MA B MA Changing Engine OilELS000CH WARNING: Be careful not to burn yourself, as the engine oil is hot. Prolonged and repeated contact with us

Page 3594 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MA-34 ENGINE MAINTENANCE (YD22DDTI) The oil filter is provided with a relief valve. INSTALLATION 1. Remove foreign materials adhering to the oil filter installation surface. 2. Apply engine oil to

Page 3595 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual ENGINE MAINTENANCE (YD22DDTI) MA-35 C D E F G H I J K MA B MA Changing Oil Filter (TYPE B)ELS000ZM REMOVAL CAUTION: Be careful not to get burned when engine and engine oil are hot. When removing,

Page 3596 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MA-36 ENGINE MAINTENANCE (YD22DDTI) 5. Remove O-ring from oil filter body. Push O-ring in one direction, lift the slack part using fingers, and remove O-ring from oil filter body. CAUTION: Do not u

Page 3597 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual CHASSIS AND BODY MAINTENANCE MA-37 C D E F G H I J K MA B MA CHASSIS AND BODY MAINTENANCEPFP:00100 Checking Exhaust SystemELS000B9 Check exhaust pipes, muffler and mounting for improper attachment,

Page 3598 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MA-38 CHASSIS AND BODY MAINTENANCE Changing M/T OilELS000BD 1. Drain oil from drain plug and refill with new gear oil. 2. Check oil level. CAUTION: Do not reuse gasket. Checking A/T FluidELS000BV 1.

Page 3599 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual CHASSIS AND BODY MAINTENANCE MA-39 C D E F G H I J K MA B MA 6. Check fluid condition. If fluid is very dark or smells burned, refer to AT section for checking operation of A/T. Flush cooling syste

Page 3600 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MA-40 CHASSIS AND BODY MAINTENANCE 2. Check oil level. CAUTION: Carefully fill the oil. (Fill up for Approx. 3 minutes.) Checking Propeller ShaftELS000BE Check propeller shaft for damage, looseness
