OIL PUMP
LU-31
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
LU
Measure the clearance with the feeler gauge and the straight-
edge.
Side clearance between inner rotor and oil pump housing (posi-
tion 3)
Side clearance between outer rotor and oil pump housing (posi-
tion 4)
Calculate the clearance between inner rotor and oil pump housing as follows.
–Measure the outer diameter of protruded portion of inner rotor
(position 5).
–Measure the inner diameter of oil pump housing with the inside
micrometer (position 6).
(Clearance) = (Inner diameter of oil pump housing) – (Outer
diameter of inner rotor)
If measured/calculated values are out of the standard, replace
oil pump assembly.
Regulator Valve Clearance
(Clearance) = (Valve hole diameter) – (Regulator valve outer diame-
ter)
If out of the standard, replace oil pump assembly.
CAUTION:
Coat regulator valve with new engine oil.
Make sure that it falls smoothly into valve hole by its own
weight.Standard : 0.050 - 0.090 mm (0.0020 - 0.0035 in)
Standard : 0.030 - 0.190 mm (0.0012 - 0.0075 in)
JLC356B
PBIC0253E
Standard : 0.045 - 0.091mm (0.0018 - 0.0036 in)
SBIA0124E
Standard : 0.040 - 0.097 mm (0.0016 - 0.0038 in)
PBIC2382E
Page 330 of 4179
LU-32
[YD22DDTi]
OIL PUMP
ASSEMBLY
Assemble in the reverse order of disassembly.
Install inner rotor and outer rotor with the punched marks on the
oil pump cover side.
JLC286B
Page 331 of 4179
![NISSAN X-TRAIL 2003 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
LU-33
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
LU
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitEBS00CTZ
OIL PRESSURE
OIL PUMP
Unit: mm (in)
REGULAT NISSAN X-TRAIL 2003 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
LU-33
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
LU
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitEBS00CTZ
OIL PRESSURE
OIL PUMP
Unit: mm (in)
REGULAT](/manual-img/5/57404/w960_57404-330.png)
SERVICE DATA AND SPECIFICATIONS (SDS)
LU-33
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
LU
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitEBS00CTZ
OIL PRESSURE
OIL PUMP
Unit: mm (in)
REGULATOR VALVE
Unit: mm (in)
OIL CAPACITY (APPROXIMATE)
Unit: · (Imp qt)
Tightening TorqueEBS00B0F
Unit: N·m (kg-m, ft-lb)
Unit: N·m (kg-m, in-lb)* Engine speed rpm
Approximate discharge pressure kPa (bar, kg/cm
2 , psi)
Idle speed
2,000140 (1.40, 1.43, 20.3) or more
270 (2.70, 2.75, 39.2) or more
Oil pump housing to outer rotor radial clearance 0.114 - 0.260 (0.0045 - 0.0102)
Inner rotor to outer rotor tip clearance Below 0.18 (0.0071)
Oil pump housing to inner rotor side clearance 0.050 - 0.090 (0.0020 - 0.0035)
Oil pump housing to outer rotor side clearance 0.030 - 0.190 (0.0012 - 0.0075)
Inner rotor to oil pump housing clearance 0.045 - 0.091 (0.0018 - 0.0036)
Regulator valve to valve hole clearance 0.040 - 0.097 (0.0016 - 0.0038)
With oil filter change 5.2 (4-5/8 Imp qt)
Without oil filter change 4.9 (4-3/8 Imp qt)
Dry engine (engine overhaul) 6.3 (5-1/2 Imp qt)
Oil pressure switch 13.0 - 17.0 (1.4 - 1.7, 10 - 12)
Oil pan drain plug34 (3.5, 25)
Oil filter bracket21.5 (2.2, 16)
Oil filler body (TYPE B) 22 (2.2, 16)
Oil filter (TYPE A)18 (1.8, 13)
Oil pump cover Bolts 6.9 (0.7, 61)*
Screws 6.9 (0.7, 61)*
Regulator plug54 (5.5, 40)
Water hose connector 23.6 (2.4, 17)
Oil cooler24.5 (2.5, 18)
Page 332 of 4179
LU-34
[YD22DDTi]
SERVICE DATA AND SPECIFICATIONS (SDS)
Page 333 of 4179

CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION
A
CO
ENGINE COOLING SYSTEM
QR
PRECAUTIONS .......................................................... 3
Precautions for Liquid Gasket .................................. 3
LIQUID GASKET APPLICATION PROCEDURE ..... 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
OVERHEATING CAUSE ANALYSIS .......................... 5
Troubleshooting Chart .............................................. 5
COOLING SYSTEM .................................................... 7
Cooling Circuit .......................................................... 7
System Chart ........................................................... 8
ENGINE COOLANT .................................................... 9
Inspection ................................................................. 9
LEVEL CHECK ..................................................... 9
LEAK CHECK ....................................................... 9
Changing Engine Coolant ........................................ 9
DRAINING ENGINE COOLANT ........................... 9
REFILLING ENGINE COOLANT ........................ 10
FLUSHING COOLING SYSTEM ......................... 10
RADIATOR ................................................................ 12
Removal and Installation ........................................ 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 13
INSPECTION AFTER INSTALLATION ............... 13
Checking Radiator Cap .......................................... 13
Checking Radiator .................................................. 13
RADIATOR (ALUMINUM TYPE) .............................. 14
Disassembly and Assembly ................................... 14
PREPARATION ................................................... 14
DISASSEMBLY ................................................... 14
ASSEMBLY ......................................................... 15
INSPECTION ...................................................... 17
COOLING FAN ......................................................... 18
Removal and Installation ........................................ 18
REMOVAL ........................................................... 18
INSTALLATION ................................................... 18
DISASSEMBLY AND ASSEMBLY ...................... 18WATER PUMP .......................................................... 20
Removal and Installation ........................................ 20
REMOVAL ........................................................... 20
INSPECTION AFTER REMOVAL ....................... 21
INSTALLATION ................................................... 21
INSPECTION AFTER INSTALLATION ................ 21
THERMOSTAT AND WATER CONTROL VALVE .... 22
Removal and Installation ........................................ 22
REMOVAL ........................................................... 22
INSPECTION AFTER REMOVAL ....................... 23
INSTALLATION ................................................... 23
INSPECTION AFTER INSTALLATION ................ 23
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 24
Standard and Limit .................................................. 24
CAPACITY ........................................................... 24
THERMOSTAT .................................................... 24
WATER CONTROL VALVE ................................. 24
RADIATOR .......................................................... 24
Tightening Torque ................................................... 24
YD22DDTi
PRECAUTIONS ........................................................ 25
Precautions For Liquid Gasket ............................... 25
LIQUID GASKET APPLICATION PROCEDURE ... 25
PREPARATION ......................................................... 26
Special Service Tools ............................................. 26
Commercial Service Tools ...................................... 26
OVERHEATING CAUSE ANALYSIS ........................ 27
Troubleshooting Chart ............................................ 27
COOLING SYSTEM .................................................. 29
Cooling Circuit ........................................................ 29
System Chart .......................................................... 30
ENGINE COOLANT .................................................. 31
Inspection ............................................................... 31
LEVEL CHECK .................................................... 31
Page 334 of 4179

CO-2 CHECKING RADIATOR SYSTEM FOR LEAKS ... 31
Changing Engine Coolant ....................................... 31
DRAINING ENGINE COOLANT .......................... 31
REFILLING ENGINE COOLANT ......................... 32
FLUSHING COOLING SYSTEM ......................... 33
RADIATOR ................................................................ 34
Removal and Installation ........................................ 34
REMOVAL ........................................................... 34
INSTALLATION .................................................... 34
INSPECTION AFTER INSTALLATION ................ 34
Checking Radiator Cap .......................................... 35
Checking Radiator .................................................. 35
COOLING FAN .......................................................... 36
Removal and Installation ........................................ 36
REMOVAL ........................................................... 36
INSTALLATION .................................................... 36
DISASSEMBLY AND ASSEMBLY ....................... 36
RADIATOR (ALUMINUM TYPE) ............................... 38
Disassembly and Assembly .................................... 38
PREPARATION ................................................... 38
DISASSEMBLY ................................................... 38
ASSEMBLY ......................................................... 39
INSPECTION ....................................................... 41WATER PUMP ........................................................... 42
Removal and Installation ......................................... 42
REMOVAL ............................................................ 42
INSPECTION AFTER REMOVAL ........................ 43
INSTALLATION .................................................... 43
INSPECTION AFTER INSTALLATION ................ 43
THERMOSTAT AND WATER PIPING ....................... 44
Removal and Installation ......................................... 44
REMOVAL ............................................................ 44
INSPECTION AFTER REMOVAL ........................ 45
INSTALLATION .................................................... 45
INSPECTION AFTER INSTALLATION ................ 45
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 46
Standard and Limit .................................................. 46
CAPACITY ........................................................... 46
THERMOSTAT ..................................................... 46
RADIATOR ........................................................... 46
Tightening Torque ................................................... 46
Page 335 of 4179
PRECAUTIONS
CO-3
[QR]
C
D
E
F
G
H
I
J
K
L
MA
CO
[QR]PRECAUTIONSPFP:00001
Precautions for Liquid GasketEBS00MRX
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.
Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
use) to remove adhering moisture, grease and foreign materials.
3. Attach liquid gasket tube to the tube presser (special service
tool).
Use Genuine Liquid Gasket or equivalent.
Within five minutes of liquid gasket application, install the mat-
ing component.
If liquid gasket protrudes, wipe it off immediately.
Do not retighten mounting bolts or nuts after the installation.
Wait 30 minutes or more after installation before refilling
engine oil and engine coolant.
PBIC2160E
Page 336 of 4179
CO-4
[QR]
PREPARATION
PREPARATIONPFP:00002
Special Service ToolsEBS00KOC
Commercial Service ToolsEBS011T8
Tool number
Tool nameDescription
EG17650301
Radiator cap tester adapterAdapting radiator cap tester to radiator cap
and radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
KV99103510
Radiator plate pliers AInstalling radiator upper and lower tanks
KV99103520
Radiator plate pliers BRemoving radiator upper and lower tanks
WS39930000
Tube presserPressing the tube of liquid gasket
S-NT564
S-NT224
S-NT225
S-NT052
Tool nameDescription
Radiator cap tester Checking radiator and radiator cap
PBIC1982E
