NISSAN X-TRAIL 2003 Service Repair Manual CYLINDER BLOCK EM-229 [YD22DDTi] C D E F G H I J K L MA EM Piston Pin Outer Diameter Use micrometer to measure piston pin outer diameter. Calculation of Connecting Rod Bushing Clearance (Connecting

Page 282 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EM-230 [YD22DDTi] CYLINDER BLOCK PISTON TO CYLINDER BORE CLEARANCE Cylinder Bore Inner Diameter Using bore gauge, measure cylinder inner diameters at six posi- tions; top, middle, and bottom (A, B,

Page 283 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual CYLINDER BLOCK EM-231 [YD22DDTi] C D E F G H I J K L MA EM 2. install main bearing caps and tighten bolts to the specified torque. Refer to EM-217, "ASSEMBLY" . This will prevent distortion of cylind

Page 284 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EM-232 [YD22DDTi] CYLINDER BLOCK If corrected, measure the bearing oil clearance of the corrected journal and/or pin. Then select the main bearing or connecting rod bearing. Refer to EM-233, " MAIN

Page 285 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual CYLINDER BLOCK EM-233 [YD22DDTi] C D E F G H I J K L MA EM MAIN BEARING OIL CLEARANCE Method by Measurement Install main bearings to cylinder block and bearing cap, and tighten the bolts to the spe

Page 286 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EM-234 [YD22DDTi] CYLINDER BLOCK MAIN BEARING CAP BOLT DEFORMATION Measure the outer diameter of threaded area, d1 and d2, at the points specified in the figure. When the necked point is identifie

Page 287 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual CYLINDER BLOCK EM-235 [YD22DDTi] C D E F G H I J K L MA EM FLYWHEEL DEFLECTION Measure the deflection of flywheel contact surface to clutch with a dial indicator. Measure the deflection at 210 mm

Page 288 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EM-236 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030 Standard and LimitEBS00ODZ GENERAL SPECIFICATIONS INTAKE MANIFOLD AND EXHAUST MANIFOLD Unit: mm
