NISSAN X-TRAIL 2003 Service Repair Manual PERIODIC MAINTENANCE
MA-9
C
D
E
F
G
H
I
J
K
MA
B
MA

ENGINE AND EMISSION CONTROL MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage <30,000 Km/year)
Abbreviations: I = Inspect and correct or replac

PERIODIC MAINTENANCE
MA-9
C
D
E
F
G
H
I
J
K
MA
B
MA

ENGINE AND EMISSION CONTROL MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage <30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, D = Check filter and drain water
NOTE:
Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”.
(1) If valve noise increases, check valve clearance.
(2) Never use CG-4 oil.
(3) Oil filter element assembly and O-ring seal are replacement parts.
(4) First replace at 100,000 Km (60,000 miles)/60 months, then every 60,000Km (36,000 miles)/36 months. After first
replacement, perform "I" (checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of
replacement interval.
(5) If engine power decreases, black exhaust smoke is emitted or engine noise increases, perform this maintenance item.
CHASSIS AND BODY MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage <30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L = Lubricate. MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence page Perform either at number of kilometers (miles) or
months, whichever comes first.km x 1,000
(Miles x
1,000)
Months20
(12)
1240
(24)
2460
(36)
3680
(48)
48100
(60)
60120
(72)
72
Engine compartment and under vehicle
Intake & exhaust valve clearanceSee
NOTE (1)EM-175
Drive belts I I I I I IMA-27
Engine oil (recommended oil.)See
NOTE (2)RRRRRRMA-33
Engine oil filter (Use Eco filter or equivalent)See
NOTE (3)RRRRRRMA-33
Engine anti-freeze coolant (Use Genuine Nissan
Anti-freeze Coolant (L250) or equivalent)See
NOTE (4)IRMA-28
Cooling system I I I I I IMA-30
Fuel lines I I IMA-31
Air cleaner filter RRMA-32
Fuel filterDRDRDRMA-31
Fuel injectorSee
NOTE (5)EM-157
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
page Perform either at number of kilometers (miles)
or months, whichever comes first.km x 1,000
(Miles x 1,000)
Months20
(12)
1240
(24)
2460
(36)
3680
(48)
48100
(60)
60120
(72)
72
Underhood and under vehicle
Headlamp aiming I I I I I ILT- 1 4
Brake & clutch, systems and fluid (For level &
leaks)IIIIIIMA-41, MA-37
Brake fluidRRRMA-42
Brake booster vacuum hoses, connections &
check valveIIIBR-25
Power steering fluid & lines (For level & leaks) I I I I I IMA-44
Manual transaxle gear oil (For leaks) I I I I I IMA-37
Transfer gear oil (For level & leaks) I I I I I IMA-39

Page 3570 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MA-10
PERIODIC MAINTENANCE

NOTE:
(1) Inspect once per year.
Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”.
MAIN

Page 3571 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual PERIODIC MAINTENANCE
MA-11
C
D
E
F
G
H
I
J
K
MA
B
MA

Maintenance operation: Check = Check and correct or replace as necessary.
Driving conditionMaintenance itemMainte-
nance
opera-
tionMaintenance

Page 3572 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MA-12
PERIODIC MAINTENANCE

ENGINE AND EMISSION CONTROL MAINTENANCE (QR20DE AND QR25DE PETROL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary,

Page 3573 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual PERIODIC MAINTENANCE
MA-13
C
D
E
F
G
H
I
J
K
MA
B
MA

CHASSIS AND BODY MAINTENANCE (QR20DE AND QR25DE PETROL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace

Page 3574 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MA-14
PERIODIC MAINTENANCE

ENGINE AND EMISSION CONTROL MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Repla

MA-14
PERIODIC MAINTENANCE

ENGINE AND EMISSION CONTROL MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, D = Check filter and drain water
NOTE:
Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”.
(1) If valve noise increases, check valve clearance.
(2) Never use CG-4 oil.
(3) Oil filter element assembly and O-ring seal are replacement parts.
(4) First replace at 100,000 Km (60,000 miles), then every 60,000Km (36,000 miles). After first replacement, perform "I"
(checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.
(5) If engine power decreases, black exhaust smoke is emitted or engine noise increases, perform this maintenance item.
CHASSIS AND BODY MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L = Lubricate. MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence page Perform either at number of kilometers (miles) or
months, whichever comes first.km x 1,000
(Miles x
1,000)
Months20
(12)40
(24)60
(36)80
(48)100
(60)120
(72)
Engine compartment and under vehicle
Intake & exhaust valve clearanceSee
NOTE (1)EM-175
Drive belts I I I I I IMA-27
Engine oil (Use recommended oil.)See
NOTE (2)RRRRRRMA-33
Engine oil filter (Use Eco filter or equivalent)See
NOTE (3)RRRRRRMA-33
Engine anti-freeze coolant (Use Genuine Nissan Anti-
freeze Coolant (L250) or equivalent)See
NOTE (4)IRMA-28
Cooling system IIIIIIMA-30
Fuel linesIIMA-31
Air cleaner filter RRMA-32
Fuel filterDDRDDRMA-31
Fuel injectorSee
NOTE (5)EM-157
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
page Perform either at number of kilometers (miles)
or months, whichever comes first.km x 1,000
(Miles x
1,000)
Months20
(12)40
(24)60
(36)80
(48)100
(60)120
(72)
Underhood and under vehicle
Headlamp aiming I I ILT- 1 4
Brake & clutch, systems and fluid (For level &
leaks)IIIIIIMA-41, MA-37
Brake fluidRRMA-42
Brake booster vacuum hoses, connections &
check valveIIBR-25
Power steering fluid & lines (For level & leaks) IIIIIIMA-44
Manual transaxle gear oil (For leaks) I I IMA-37
Transfer gear oil (For level & leaks)IIIIIIMA-39

Page 3575 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual PERIODIC MAINTENANCE
MA-15
C
D
E
F
G
H
I
J
K
MA
B
MA

NOTE:
(1) Inspect once per year.
Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe D

Page 3576 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual MA-16
PERIODIC MAINTENANCE

Maintenance operation: Check = Check and correct or replace as necessary.
Driving conditionMaintenance itemMainte-
nance
opera-
tionMaintenance intervalRefer-
ence
page
