TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-93
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
Torque converter is not locked up. ON vehicle1. Accelerator pedal position (APP) sensorAT-173
2. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 11 2, AT- 1 9 2
3. Engine speed signalAT- 11 9
4. A/T fluid temperature sensorAT-184
5. Line pressure testAT- 6 8
6. Torque converter clutch solenoid valveAT-148
7. Control valve assemblyAT-404
Torque converter is not locked up. OFF vehicle 8. Torque converterAT-423
Torque converter clutch piston slip.ON vehicle1. Fluid levelAT- 6 4
2. Accelerator pedal position (APP) sensorAT-173
3. Line pressure testAT- 6 8
4. Torque converter clutch solenoid valveAT-148
5. Line pressure solenoid valveAT-154
6. Control valve assemblyAT-404
OFF vehicle 7. Torque converterAT-423
Lock-up point is extremely high or
low.
AT- 2 2 4
ON vehicle1. Accelerator pedal position (APP) sensorAT-173
2. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 11 2, AT- 1 9 2
3. Torque converter clutch solenoid valveAT-148
4. Control valve assemblyAT-404
A/T does not shift to “D4 ” when driv-
ing with overdrive control switch
“ON”.ON vehicle1. Accelerator pedal position (APP) sensorAT-173
2. PNP switchAT-100
3. Overdrive control switchAT-237
4. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 11 2, AT- 1 9 2
5. Shift solenoid valve AAT-161
6. Overrun clutch solenoid valveAT-178
7. Control valve assemblyAT-404
8. A/T fluid temperature sensorAT-184
9. Line pressure testAT- 6 8
A/T does not shift to “D4 ” when driv-
ing with overdrive control switch
“ON”.OFF vehicle10. Brake bandAT-497
11. Overrun clutchAT-475
Engine is stopped at “R”, “D”, “2”
and “1” positions.ON vehicle1. Fluid levelAT- 6 4
2. Torque converter clutch solenoid valveAT-148
3. Shift solenoid valve AAT-161
4. Shift solenoid valve BAT-167
5. Control valve assemblyAT-404
Symptom Condition Diagnostic Item Reference Page
Page 2130 of 4179
![NISSAN X-TRAIL 2003 Service Repair Manual AT-94
[EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
TCM Terminals and Reference ValueECS004QV
PREPARATION
Measure voltage between each terminal and terminal 25 or 48
by following “TCM INSP NISSAN X-TRAIL 2003 Service Repair Manual AT-94
[EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
TCM Terminals and Reference ValueECS004QV
PREPARATION
Measure voltage between each terminal and terminal 25 or 48
by following “TCM INSP](/manual-img/5/57404/w960_57404-2129.png)
AT-94
[EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
TCM Terminals and Reference ValueECS004QV
PREPARATION
Measure voltage between each terminal and terminal 25 or 48
by following “TCM INSPECTION TABLE”.
TCM CONNECTOR TERMINAL LAYOUT
TCM INSPECTION TABLE
(Data are reference values.)
SAT216J
SCIA0495E
Te r m i -
nal No.Wire color Item ConditionJudgementstan-
dard(Approx.)
1R/WLine pressure
solenoid valveWhen releasing accelerator pedal
after warming up engine.1.5 - 3.0V
When depressing accelerator pedal
fully after warming up engine.0V
2P/BLine pressure
solenoid valve
(with dropping
resistor)When releasing accelerator pedal
after warming up engine.5 - 14V
When depressing accelerator pedal
fully after warming up engine.0V
3GY/RTorque converter
clutch solenoid
valveWhen A/T performs lock-up. 8 - 15V
When A/T does not perform lock-up. 0V
5 G/R CAN-H — —
6 GY/R CAN-L — —
10 BR/W Power source
or When turning ignition switch to “ON”. Battery voltage
When turning ignition switch to
“OFF”.0V
Page 2131 of 4179
![NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-95
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
11 L / WShift solenoid
valve AWhen shift solenoid valve A oper-
ates.
(When driving in “D1 ” or “D4 ”.)B NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-95
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
11 L / WShift solenoid
valve AWhen shift solenoid valve A oper-
ates.
(When driving in “D1 ” or “D4 ”.)B](/manual-img/5/57404/w960_57404-2130.png)
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-95
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
11 L / WShift solenoid
valve AWhen shift solenoid valve A oper-
ates.
(When driving in “D1 ” or “D4 ”.)Battery voltage
When shift solenoid valve A does not
operate.
(When driving in “D
2 ” or “D3 ”.)0V
12 L/YShift solenoid
valve BWhen shift solenoid valve B oper-
ates.
(When driving in “D
1 ” or “D2 ”.)Battery voltage
When shift solenoid valve B does not
operate.
(When driving in “D
3 ” or “D4 ”.)0V
19 BR/W Power source
or Same as No. 10
20 L/BOverrun clutch
solenoid valveWhen overrun clutch solenoid valve
operates.Battery voltage
When overrun clutch solenoid valve
does not operate.0V
25 B Ground Always 0V
26 BR/YPNP switch “1”
position
and When setting selector lever to “1”
position.Battery voltage
When setting selector lever to other
positions.0V
27 LPNP switch “2”
positionWhen setting selector lever to “2”
position.Battery voltage
When setting selector lever to other
positions.0V
28 LPower source
(Memory back-up) Always Battery voltage
29 W/R Revolution sensorWhen moving at 20 km/h (12 MPH) 450 Hz
When vehicle parks.Under 1.3V or
over 4.5V
30 *2 G/B CONSULT- II (RX) — —
31 *2 W CONSULT- II (TX) — —
32 *1 RAccelerator pedal
position (APP)
sensor
(Power source) or When turning ignition switch to “ON”. 4.5 - 5.5V
When turning ignition switch to
“OFF”.0V Termi-
nal No.Wire color Item ConditionJudgementstan-
dard(Approx.)
Page 2132 of 4179
![NISSAN X-TRAIL 2003 Service Repair Manual AT-96
[EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
*1: These terminals are connected to the ECM.
*2: These terminals are connected to the data link connector.34 W/GPNP switch “D”
positi NISSAN X-TRAIL 2003 Service Repair Manual AT-96
[EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
*1: These terminals are connected to the ECM.
*2: These terminals are connected to the data link connector.34 W/GPNP switch “D”
positi](/manual-img/5/57404/w960_57404-2131.png)
AT-96
[EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
*1: These terminals are connected to the ECM.
*2: These terminals are connected to the data link connector.34 W/GPNP switch “D”
position
and When setting selector lever to “D”
position.Battery voltage
When setting selector lever to other
positions.0V
35 Y/GPNP switch “R”
positionWhen setting selector lever to “R”
position.Battery voltage
When setting selector lever to other
positions.0V
36 GPNP switch “P”,
“N” positionWhen setting selector lever to “P”,
“N” position.Battery voltage
When setting selector lever to other
positions.0V
39 *1 L/OREngine speed sig-
nal
and Refer to EC-95
.—
40 L/BVehicle speed
sensorWhen moving vehicle at 2 to 3 km/h
(1 to 2 MPH) for 1 m (3 ft) or more.Voltage varies
between less
than 0V and
more than 4.5V
41 G/YAccelerator pedal
position (APP)
sensorWhen depressing accelerator pedal
slowly after warming up engine.
(Voltage rises gradually in response
to throttle position.)Fully-closed
throttle: 0.5V
Fully-open throt-
tle: 4V
42 B Sensor ground Always 0V
47 BRA/T fluid tempera-
ture sensorWhen ATF temperature is 20°C
(68°F).1.5V
When ATF temperature is 80°C
(176°F).0.5V
48 B Ground Always 0V Te r m i -
nal No.Wire color Item ConditionJudgementstan-
dard(Approx.)
Page 2133 of 4179
![NISSAN X-TRAIL 2003 Service Repair Manual DTC U1000 CAN COMMUNICATION LINE
AT-97
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
DTC U1000 CAN COMMUNICATION LINEPFP:31940
DescriptionECS008CZ
CAN (Controller Area Network) is a serial communication line NISSAN X-TRAIL 2003 Service Repair Manual DTC U1000 CAN COMMUNICATION LINE
AT-97
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
DTC U1000 CAN COMMUNICATION LINEPFP:31940
DescriptionECS008CZ
CAN (Controller Area Network) is a serial communication line](/manual-img/5/57404/w960_57404-2132.png)
DTC U1000 CAN COMMUNICATION LINE
AT-97
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
DTC U1000 CAN COMMUNICATION LINEPFP:31940
DescriptionECS008CZ
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
On Board Diagnosis LogicECS008D0
Possible CauseECS00CUO
Harness or connectors
(CAN communication line is open or shorted.)
DTC Confirmation ProcedureECS008D1
NOTE:
If “DTC Confirmation Procedure” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Wait at least 6 seconds or start engine and wait for at least 6
seconds.
4. If DTC is detected, go to AT- 9 9 , "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-II”
WITHOUT CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Wait at least 6 seconds or start engine and wait at least 6 seconds.
3. Perform self-diagnosis.
Refer to AT- 5 2 , "
Diagnostic Procedure Without CONSULT-II" .
4. If DTC is detected, go to AT- 9 9 , "
Diagnostic Procedure" .
Diagnostic trouble code Malfunction is detected when... Check items (Possible cause)
:CAN COMM CIRCUIT
When a malfunction is detected in CAN
communication line.
Harness or connectors
(CAN communication line is open or
shorted.) :11th judgement flicker
SAT014K
SCIA4673E
Page 2134 of 4179
AT-98
[EURO-OBD]
DTC U1000 CAN COMMUNICATION LINE
Wiring Diagram — AT — CANECS008D2
TCWA0234E
Page 2135 of 4179
DTC U1000 CAN COMMUNICATION LINE
AT-99
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
TERMINALS AND REFERENCE VALUE MEASURED BETWEEN EACH TERMINAL
Diagnostic ProcedureECS008D3
1. CHECK CAN COMMUNICATION CIRCUIT
With CONSULT-II
1. Turn ignition switch “ON” and start engine.
2. Select “SELF-DIAG RESULTS” mode for “A/T” with CONSULT-
II.
Is any malfunction of the
“CAN COMM CIRCUIT” indicated?
YES >> Print out CONSULT-II screen, GO TO LAN section.
Refer to LAN-4, "
CAN Communication Unit" .
NO >>INSPECTION END
Te r m i -
nal No.Wire color Item ConditionJudgement
standard
(Approx.)
5 G/R CAN-H — —
6 GY/R CAN-L — —
PCIA0061E
Page 2136 of 4179
![NISSAN X-TRAIL 2003 Service Repair Manual AT-100
[EURO-OBD]
DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH
DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCHPFP:32006
DescriptionECS004QW
The PNP switch assembly includes a transmission range switch NISSAN X-TRAIL 2003 Service Repair Manual AT-100
[EURO-OBD]
DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH
DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCHPFP:32006
DescriptionECS004QW
The PNP switch assembly includes a transmission range switch](/manual-img/5/57404/w960_57404-2135.png)
AT-100
[EURO-OBD]
DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH
DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCHPFP:32006
DescriptionECS004QW
The PNP switch assembly includes a transmission range switch.
The transmission range switch detects the selector lever posi-
tion and sends a signal to the TCM.
On Board Diagnosis LogicECS00CTG
Possible CauseECS00CTH
Harness or connectors
[The park/neutral position (PNP) switch circuit is open or shorted.]
Park/neutral position (PNP) switch
DTC Confirmation ProcedureECS00CTI
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously conducted, always turn ignition switch “OFF”
and wait at least 5 seconds before conducting the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
SCIA0752E
Diagnostic trouble code Malfunction is detected when... Check items (Possible cause)
: PNP SW/CIRC
TCM does not receive the correct voltage
signal from the switch based on the gear
position.
Harness or connectors
(The PNP switch circuit is open or
shorted.)
PNP switch : P0705
SAT014K
