Page 905 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS EC-527 [QR (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC 3. CHECK TARGET IDLE SPEED With CONSULT-II 1. Run engine at about 2,000 rpm for about 2 minutes under no-load. 2. Rev engi

Page 906 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-528 [QR (WITHOUT EURO-OBD)] TROUBLE DIAGNOSIS 6. PERFORM IDLE AIR VOLUME LEARNING Refer to EC-508, " Idle Air Volume Learning" . Is Idle Air Volume Learning carried out successfully? Ye s o r N

Page 907 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS EC-529 [QR (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC 10. CHECK IGNITION TIMING 1. Run engine at idle. 2. Check ignition timing with a timing light. OK or NG OK >>INSPECTION END

Page 908 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-530 [QR (WITHOUT EURO-OBD)] TROUBLE DIAGNOSIS 14. CHECK TARGET IDLE SPEED AGAIN With CONSULT-II 1. Start engine and warm it up to normal operating temperature. 2. Read idle speed in “DATA MONI

Page 909 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS EC-531 [QR (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC 17. DETECT MALFUNCTIONING PART Check the following. Check camshaft position sensor (PHASE) and circuit. Refer to EC-646 .

Page 910 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-532 [QR (WITHOUT EURO-OBD)] TROUBLE DIAGNOSIS Symptom Matrix ChartEBS010X8 SYSTEM — BASIC ENGINE CONTROL SYSTEM SYMPTOM Reference page HARD/NO START/RESTART (EXCP. HA) ENGINE STALL HESITATION/

Page 911 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS EC-533 [QR (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC 1 - 6: The numbers refer to the order of inspection. (continued on next page)ECM 22333333333EC-661 , EC-664 Intake valve t

Page 912 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-534 [QR (WITHOUT EURO-OBD)] TROUBLE DIAGNOSIS SYSTEM — ENGINE MECHANICAL & OTHER SYMPTOM Reference page HARD/NO START/RESTART (EXCP. HA) ENGINE STALL HESITATION/SURGING/FLAT SPOT SPARK KNOCK/D
